Connect the ISC-8000 Series Camera
The ISC-8000 series camera's I/O connector provides connection to the camera's
acquisition trigger and strobe output. The camera's ENET connector provides an
Ethernet connection and Power over Ethernet (PoE) to the camera. Refer to the
ISC-8000 Series Camera Reference Guide for complete camera installation steps
and specifications.
CAUTION: Cognex recommends only cold-plugging the camera; turn the
vision controller power off when connecting or disconnecting the camera.
1. Optionally, connect the Breakout cable's M8 connector to the camera's I/O
connector.
CAUTION:
standard components. To reduce emissions, the ferrite must be
attached to the Breakout cable, adjacent to the strain relief on the
cable.
A ferrite is included with the In-Sight 8405 camera
