ENGLISH
WARNING:
• Keep the drainage cover and the water plugproperly in place.
• During drainage, the body can be tilted slightly backwards.
• If the water container cannot hold all the water, before the water
container is full, stuff the water outlet with the water plug as soon
as possible to prevent water from flowing to the floor or the carpet.
• When the water is spilt, place the water lid and tighten the drainage
cover.
• Restart the machine after the water plug and drainage cover are
installed, otherwise condensate water of the machine will flow to the floor or the carpet.
Continuous drainage (Optional):
This function can only be activated with cooling and degumidifying mode.
• Unscrew the drainage cover, and remove the water lid.
• Place the drainage pipe in the water outlet.
• Point the drainage pipe towards the bucket.

5. CLEANING AND MAINTENANCE

CLEANING
IMPORTANT: before cleaning and maintenance, turn off the machine and unplug it from the
power supply.
Surface cleaning
Clean the device's surface with a wet soft cloth. Don't use chemicals, such as benzene, alcohol,
gasoline, etc.; otherwise, the surface of the local air conditioner as well as its operating could
be affected.
Filter cleaning
If the filter screen is clogged with dust, and the effectiveness of the local air
conditioner is reduced, clean the filter screen once every two weeks.
Cleaning the filter's upper frame:
• Push down the frame from the outside to remove the EVA filter
screen frame. Unscrew four screws fixing the EVA filter screen and
the rear housing to remove the EVA filter screen (as shown in the
above figure).
• Put the EVA filter screen into warm water with neutral detergent
(about 40 ºC/ 104 ºF) and allow it to dry (not exposed to sun light)
after rinsing clean.
26 FORCECLIMA 7050
05244_FORCECLIMA 7000_Manual_LI_MV.indd 26
Remove screws
