Cleaning And Maintenance - cecotec FORCECLIMA 7400 SOUNDLESS TOUCH Bedienungsanleitung

ENGLISH
Condensate water flooding protection function
When the water level exceeds the maximum level allowed by the safety buoy, the appliance
will switch off and activate the FULL indicator on the control panel. To restart the device, the
water inside the device will need to be drained through the bottom drain plug (shown in detail
in the drainage instructions section). Once the water has been drained, the device will restart.
Automatic defrost
This air conditioner has an automatic defrost function.
Compressor protection function
To increase the service life of the compressor, it has a 3-minute delay booting protection
function after the compressor is turned off.

5. CLEANING AND MAINTENANCE

- Turn off and unplug the product from the power supply before cleaning or repairing it.
- Use a soft, dry (or slightly damp) cloth with some neutral cleaning agent to clean the
product's outside and prevent the accumulation of dust and dirt.
- If the product is not going to be used for a long time, store it in a safe and well-ventilated
place.
- Do not use detergent, scouring pads, chemically-treated cloths, petrol, benzene, alcohol,
thinner, or other solvents, as these can scratch and damage the tank and cause water
leakage.
- Do not immerse the product in water or other liquids.
Cleaning the filter. Fig. 12
- If the filter is clogged with dust, the effectiveness of the air conditioning will be reduced.
Make sure to clean the filter once every two weeks.
- Cleaning the upper filter frame
- Unscrew the screw attached to the filter at the rear with a screwdriver and remove the
filter.
- Put the filter screen into warm water with neutral detergent (about 40 ºC / 104 ºC) and
dry it in the shade after rinsing clean. Make sure it is completely dry before reattaching it.
Replacing batteries
The remote control is powered by two AAA batteries. If the remote control does not respond,
replace the batteries as follows:
1. Put the remote control face down and slide the tab outwards.
2. Remove the batteries.
3. Insert the batteries paying attention to polarity.
62 FORCECLIMA 7400 SOUNDLESS TOUCH
Storage
- Store the device in well ventilated areas.
- Unscrew the drain cap, unplug the water plug, and discharge the water in the water tank
into other water containers or directly tilt the body to discharge the water into other
containers.
- Turn on the appliance, adjust it to low-wind ventilation mode, and maintain this state until
the drainage pipe becomes dry. This way, you will keep the inside of the body in a dry state
and prevent it from mildewing.
- Turn off the appliance, unplug the power plug, and wrap the power cord around the
wrapping post. Install the water plug and the drain cap.
- Remove the exhaust pipe and keep it properly.
- Cover the air conditioning with a plastic bag. Put the air conditioning in a dry place, keep it
out of the reach of children, and take dust control measures.
- Remove batteries of the remote control and keep them properly.
- Ensure that the body is placed in a dry place and keep all machine components properly.
Maintenance
Any person who is involved with working on or breaking into a refrigerant circuit should hold a
current valid certificate from an industry-accredited assessment authority, which authorises
their competence to handle refrigerants safely in accordance with an industry recognised
assessment specification.
6. TROUBLESHOOTING
Problems Possible causes
The air There is no electricity.
conditioning
does not
The full-tank indicator will
work.
flash.
The room temperature is
too low or too high.
In cooling mode, the room
temperature is lower than
the set temperature; in
heating mode, the room
temperature is higher than
the set temperature.
In dehumidification mode,
the room temperature is
very low.
ENGLISH
Possible solutions
Turn it on after connecting it to a socket
with electricity.
Discharge the water inside.
It is recommended using the appliance in at
the temperature of 7-35 ºC.
Change the set temperature.
The appliance is in a room with a
temperature below 17°C.
FORCECLIMA 7400 SOUNDLESS TOUCH 63
