- ASSEMBLING THE BASE -

(for models 319 902, 319 903)
1
1.
Assemble 9 and 10 using provided nuts, bolts and wrench
2
2. Assemble 12 and (9/10) using provided nuts, bolts and
wrench
3
3. Position shelf 13 between the base supports, spreading them
slightly if necessary
4
4. Clip the barbecue onto the two frame pieces (9)
Ref: 319 001
- ASSEMBLING THE SHELVES -
(model 319 903 only)
5
5.
2
1
3
7
6
8
5
4
9
10
13
Ref: 319 002
40
Attach shelves to main assembly using chrome-plated rods
15
11
12
14
Ref: 319 003
