System configuration

Table of Configuration I
Use IR
Remote
Symbol
IR Address rAdr
Cold draft UCFG
note 1
Thermistor
CCN address Uadr
Electric ZONE
Heater
Options
Dead band GFdn
Off / ECO a St
Note 1: When set as Chilled Beam, the Cold Draft thermistor must be installed.
Table of Configuration II
Item Value
Ab: Both
"CH"
A: A only
B: B only
"tU"
C: Degrees C
f: Degrees f
HP: normal operation
"rc"
CO: cooling only
17 – 32 : 17° - 32° C
"HR"
63 – 90 : 63° - 90 °F
17 – 32 : 17° - 32° C
"CR"
63 – 90 : 63° - 90 °F
12 : Standard time 12 (AM/PM)
"CL"
24 : hours 24
address selector "IR"
address selector "IR"
If you are installing two indoor units in the same room and you want
them to operate in independent mode with Infrared user interface,
it is necessary to assign each unit own IR address so that each unit
can operate via its own remote control.
For configuration, proceed as follows:
• Switch the remote control off (OFF).
Configuration (of the unit)
• Press the and buttons of the infrared remote control and
hold them pressed for more than 5 seconds.
• The display will be cleared, the time segments will display the first
configuration item (rAdr = remote address) and the temperature
segments will display the default value of this configuration item
(Ab = control of both indoor units).
• Press either the or button to change the default value (ab)
to the new value (a) or (b).
• Press button to transmit the new configuration to the unit.
• Press button to leave the configuration menu.
GB - 6
IR Values available
Remote
Value
ab, a,B A - Address A
B - Address B
AB - Both
HP, aC HP - Cold draft thermistor installed
AC - Cold draft thermistor not installed
1 - 240 1 - 240
0 - 240
0 - Not installed
1 - Low power without booster heating
2 - Low power with booster heating
minimum fan speed is low when
booster heating is active
3 - Low power with booster heating
minimum fan speed is medium when
booster heating is active
4 - Low power with booster heating
minimum fan speed is high when
booster heating is active
5 - 240 high power
1 - 240 < 2 is equal to 2
2 - 6
> 6 is equal to 6
On, OF
0F- Turning unit off, unit is really off (only
antifreeze Protection is active)
On- Turning unit off, ECO mode is active
Description
Remote ID selection
Default code ab
Temperature unit
Default code C
Remote terminal is defined by cooling only mode
Default code: HP
Maximum setpoint in heating mode (C or °F according to "rc")
Minimum setpoint in cooling mode (C or °F according to "rc")
Time format
Default code 12
CRC Default values from CRC
Remote
Symbol
20 1 - Cold draft thermistor installed
0 - Cold draft thermistor not installed
21 1 - 199
22 0 - not installed
1 - Low power without booster heating
2 - Low power with booster heating
minimum fan speed is low when
booster heating is active
3 - Low power with booster heating
minimum fan speed is medium when
booster heating is active
4 - Low power with booster heating
minimum fan speed is high when
booster heating is active
5 - 199 high power
23 < 2 is equal to 2
2 - 6
> 6 is equal to 6
24
0- Turning unit off, unit is really off (only
antifreeze Protection is active)
1- Turning unit off, ECO mode is active
Configuration (of the remote controller)
• Press the and buttons of the infrared remote control and
hold them pressed for more than 5 seconds.
• The display will be cleared, the temperature segments will display
the first configuration item (CH = remote address) and the time
segments will display the default value of this configuration item
(Ab = control of both indoor units).
or button to change the default value (ab)
• Press either the
to the new value (a) or (b).
• Press button to transmit the new configuration to the unit.
• Press button to leave the configuration menu.
Note:
When 30 seconds have elapsed and no buttons have been
pressed, the remote control will automatically exit the configuration
menu and the procedure has to be restarted.
