Configuration

To access the Configuration menu:
1. Set the remote control in the Unoccupied
mode by pressing the Occupancy button
2. Press and hold the Menu button
least 5 seconds.
3. "1." is displayed. The number represents the
parameter to be set (see the table below).
Item Parameter Value
1. Temperature F / C
2. System Co / St
3. Setpoint Yes / No The setpoint may or may not be displayed
display
4. Setpoint 15 to
value 32°C
5. Reset step 0 to 2°C The reset step value can be adjusted:
value
6. Fan speed F / U
type
7. Blinds group 0
1
2
3
4
8. Blinds No / Yes Not applicable
inclination
9. Lights group 0
1
2
3
4
10. Louver No / Yes The presence of the louvers depends on
presence
11. Unit's A, 1-7
remote ID
for at
Description
F: Fahrenheit
C: Celsius
Co: Temperature setpoint - bar graph
St: Temperature setpoint - digital display
on the remote, depending on system
configuration (see item 2 above).
Setpoint value set within the setpoint
range.
C0 = 0°C
C0.5 = 0.5°C
C1 = 1°C
C1.5 = 1.5°C
C2 = 2°C
F = Fixed speed
U = Variable speed
0 = Blinds control is disabled
1 = 1 blinds group controlled
2 = 2 blinds groups controlled
3 = 3 blinds groups controlled
4 = 4 blinds groups controlled
0 = Lights control is disabled
1 = 1 lights group controlled
2 = 2 lights groups controlled
3 = 3 lights groups controlled
4 = 4 lights groups controlled
the type of the fan coil. Some fan coils
are not fitted with louvers.
A = Unit remote ID ALL
Unit remote ID 1; Unit remote ID 2;
Unit remote ID 3; Unit remote ID 4;
Unit remote ID 5; Unit remote ID 6;
Unit remote ID 7
To set specific parameters
1. Access the Configuration menu.
2. Navigate to the specific parameter using
.
the Up button
3. To set the parameter, press the Menu
button .
4. Press the Up button
button to set the new value for a
given parameter.
5. Press the Fan speed button
the change.
6. To display / change another item, press
the Menu button
steps given above.
If no button is pressed for more than 1 minute,
the system quits the menu automatically.
No message is sent.
Default
C
Co
Yes
22°C
0.5°C
F
0
-
0
No
A
or the Down button
or the Down
to save
and follow the
Impact on display
Yes – Only if System is St
(see item 2 below)
Yes
Yes
No
Yes – Only if System is St
(see item 2 above).
Yes - The fan speed icon
differs depending on the
selected fan speed.
Yes – When the blinds
control is enabled, the
blinds icon is displayed on
the screen.
-
Yes – When the lights con-
trol is enabled, the lights
icon is displayed on the
screen.
Yes – For units with
louvers, the louver icon is
displayed on the screen.
Yes
.
5
