Gemü R649 eSyDrive Betriebsanleitung Seite 24

7 Abmessungen
7.2.10 Flansch EN (Code 4)
MG DN
FTF H
20 15 130,0 36,0
20 150,0 38,0
25 160,0 39,0
25 32 180,0 41,0
40 40 200,0 63,2
50 230,0 63,2
50 65 290,0 78,8
Maße in mm, MG = Membrangröße
1) Anschlussart
Code 4: Flansch EN 1092, PN 10, Form B, Baulänge FTF EN 558 Reihe 1, ISO 5752, basic series 1
2) Werkstoff Ventilkörper
Code 1: PVC-U, grau
Code 5: PP, verstärkt
Code 20: PVDF
Code 71: Inliner PP-H, grau, Outliner PP, verstärkt
Code 75: Inliner PVDF/Outliner PP, verstärkt
GEMÜ R649
FTF
1 5, 20 71,
75
H1 øD
10,0 95,0 - 95,0
12,0 105,0 - 105,0
13,0 115,0 - 115,0
15,0 140,0 - 140,0
23,2 150,0 - 150,0
23,2 165,0 - 165,0
38,8 185,0 185,0 -
1)
Anschlussarten Code 4
2)
Werkstoffe Code
1 5, 20 71,
75
øL
14,0 - 14,0 45,0
14,0 - 14,0 58,0
14,0 - 14,0 68,0
18,0 - 18,0 78,0
18,0 - 18,0 88,0
18,0 - 18,0 102,0
18,0 18,0 - 122,0 122,0
24 / 41
1 5, 20 71, 1
75
ød
- 45,0 65,0
- 58,0 75,0
- 68,0 85,0
- 78,0 100,0
- 88,0 110,0
- 102,0 125,0
- 145,0 145,0
www.gemu-group.com
5, 20 71,
75
øk
- 65,0
- 75,0
- 85,0
- 100,0
- 110,0
- 125,0
-
