HYDRIUM
OWNER'S MANUAL
Item No. Dimension Kit Type
#56566
3.00 m x 1.20 m
#56563
#56567
(10' x 48")
#56564
#56574
Aboveground
#56571
3.60 m x 1.20 m
swimming
#56575
(12' x 48")
pool kit
#56572
#56384
#56382 4.60 m x 1.20 m
#56385
(15' x 48")
#56383
! WARNING !
Carefully read, understand, and follow all information
in this user manual before installing and using the
swimming pool. These warnings, instructions, and safety
guidelines address some common risks of water recreation, but they cannot cover all risks and
dangers in all cases. Always use caution, common sense, and good judgment when enjoying
any water activity. Retain this information for future use.
Non Swimmers safety
- Continuous, active, and vigilant supervision of weak swimmers and non-swimmers by a
competent adult is required at all times (remembering that children under five are at the
highest risk of drowning).
- Designate a competent adult to supervise the pool each time it is being used.
- Weak swimmers or non-swimmers should wear personal protection equipment when using
the pool.
- When the pool is not in use, or unsupervised, remove all toys from the swimming pool and
its surrounding to avoid attracting children to the pool.
Safety devices
- In order to prevent children from drowning, it is recommended to secure the access to the
pool with a protection device. In order to prevent children climbing from the inlet and outlet
valve, it is recommended to install a barrier (and secure all doors and windows, where
applicable) to prevent unauthorized access to the swimming pool.
- Barriers, pool covers, pool alarms, or similar safety devices are helpful aids, but they are
not substitutes for continuous and competent adult supervision.
Safety equipment
- It is recommended to keep rescue equipment (e.g. a ring buoy) by the pool.
- Keep a working phone and a list of emergency phone numbers near the pool.
Safe use of the pool
- Encourage all users especially children to learn how to swim.
- Learn Basic Life Support (Cardiopulmonary Resuscitation - CPR) and refresh this
knowledge regularly. This can make a life-saving difference in the event of an emergency.
- Instruct all pool users, including children, what to do in case of an emergency.
- Never dive into any shallow body of water. This can lead to serious injury or death.
- Do not use the swimming pool when using alcohol or medication that may impair your
ability to safely use the pool.
- When pool covers are used, remove them completely from the water surface before
entering the pool.
- Protect pool occupants from water related illnesses by keeping the pool water treated and
practicing good hygiene. Consult the water treatment guidelines in the user's manual.
- Store chemicals (e.g. water treatment, cleaning or disinfection products) out of the reach of
children.
- Use the signage as outlined below. Signage is to be displayed in a prominent position
within 2m of the pool.

PART LIST

No. Name
1 Upper Joint Protector
2 Top Platform
3
M6x11 Bolt
4 Top Metal Piece
5
M6 Nut
6 Skimmer
7
Hose Adaptor
8 Rail Connector
9
Rail
10 Liner
11
3M Self-adhesive tape
12 Steel wall
13
Pool Vertical Support
14 Bottom Metal Piece
15
Bottom Joint Protector
16 ST4x14 Screw
17 Control Valve
18 Pool Inlet Strainer
19 Clips
20 Foam protector
POOLS
TM
Accessories
Filtration
System
Ladder
Ground
Cloth
Material
PP
Coated Steel
Stainless Steel 304
Steel
Stainless Steel 304
PP
PVC
PVC
Coated Steel
Coated Steel
Steel
PP
Stainless Steel 304
Plastic
EPE
- Keep children under supervision in the aquatic environment. No diving.
- Removable ladders shall be placed on a horizontal surface.
- Irrespective of materials used for swimming pool construction, accessible surfaces have to
be checked regularly to avoid injuries.
- Regularly monitor bolts and screws; splinters or any sharp edges to avoid injuries.
ATTENTION: Do not leave the drained pool outside. The empty pool is liable to being
deformed and/or displaced due to wind.
- If have a filter pump, refer to the pump's manual for instructions.
WARNING! The pump cannot be used while people are inside the pool!
- If have a ladder, refer to the ladder's manual for instructions.
WARNING! The use of a swimming pool implies compliance with the safety instructions
described in the operating and maintenance guide. In order to prevent drowning or other
serious injuries, pay particular attention to the possibility of unexpected access to the
swimming pool by children under 5 years by securing the access to it, and, during the
bathing period, keep them under constant adult supervision.
NOTE: When installing the pool, the position of skimmer should be opposite to the main
wind direction. The placement of the ladder in the pool shall be away from the skimmer.
Please read carefully and keep for future reference.

Parts Reference

10' x 48''
Qty Spare Part No. Qty
P6743
8 8
8 P6744 8
122 P6746 122
8 P6747 8
26 P6748 26
1 P6762 1
2 F6H202 2
32 P6990 32
16 P6750 16
1 56284ASS17 1
1 P6756 1
1 P61452 1
8 P6757 8
8 P6761 8
8 P6759 8
16 P61491 16
1 P6(H1)1229 1
1 P6H1317 1
20 20
8 P61473 8
5
01 02
04 05
07 08
09
10 11
14 15
17 18
12' x 48'' 15' x 48''
Spare Part No. Qty Spare Part No.
P6743 P6743
10
P6745 10 P61233
P6746 146 P6746
P6747 10 P6747
P6748 26 P6748
P6762 1 P6762
F6H202 2 F6H202
P6990 40 P6990
P6751 20 P61235
56285ASS17 1 56384ASS17
P6756 1 P6756
P61453 1 P61454
P6757 10 P6757
P6761 10 P6761
P6759 10 P6759
P61491 20 P61491
P6(H1)1229 1 P6(H1)1229
P6H1317 1 P6H1317
20
P61473 10 P61473
03
06
12 13
16
19 20
S-S-005666
