hunderbolt AIC
Connector
(5-pin TBT1)
(see p.1, No. 43)
Serial Port Header
(9-pin COM1)
(see p.1, No. 41)
TPM Header
(17-pin TPMS1)
(see p.1, No. 36)
26
RRXD1
DDTR#1
DDSR#1
CCTS#1
1
RRI#1
RRTS#1
GND
TTXD1
DDCD#1
1
Please connect a hunderbolt™
add-in card (AIC) to this
connector via the GPIO cable.
*Please install the hunderbolt™
AIC card to PCIE3 (default
slot).
his COM1 header
supports a serial port
module.
his connector supports Trusted
Platform Module (TPM) system,
which can securely store keys,
digital certiicates, passwords,
and data. A TPM system also
helps enhance network security,
protects digital identities, and
ensures platform integrity.
