raggiungibile dagli utenti che stanno usando la spa.
È obbligatorio il rispetto di questa prescrizione: qualsiasi
altra procedura è vietata.
I
I dispositivi di disconnessione devono essere previsti nella rete
di alimentazione in conformità alle regole d'installazione.
I
L'installazione di dispositivi elettrici ed apparecchi (prese, inter-
ruttori, ecc.) nelle vicinanze della spa deve essere conforme alle
disposizioni di legge e norme del Paese in cui viene installata la
spa.
I
Ai fini del collegamento equipotenziale previsto dalle specifiche
norme nazionali, l'installatore dovrà usare il morsetto predisposto
(norme EN 60335.2.60) sulla cassetta elettrica (
distinto dal simbolo
.
In particolare, dovrà essere realizzata l'equipotenzialità di tutte le
masse metalliche circostanti la minipiscina, ad esempio tubazioni
idriche, del gas, eventuali pedane metalliche perimetrali, ecc.
I
L'apparecchiatura è provvista di sistema d'illuminazione a led conforme
alle norme EN 62471:2009.
ATTENZIONE! Scollegare l'apparecchiatura dalla linea
di alimentazione elettrica prima di effettuare qualsiasi
intervento di manutenzione.
It is the responsibility of the installer/owner to ascer-
tain compliance with specific local regulations prior to
installation.
Jacuzzi Europe S.p.A. gives no guarantee in this respect
and refuses all responsibility regarding compliance of
the installation carried out.

Technical Features

i
The Oxia model spa ( 1;
2Hp pump.
The skimmer contains 1 filtering cartridge to ensure water fil-
tering. The filtering surface is 2.3 m
Oxia Performance: in this case, the filtering action is provid-
ed by a sand filter (provided separately, with a circulation pump
and a support base, see the corresponding installation manual).
Maximum absorption of the system
i
4), e contrad-
i
2) is provided with one 2-speed
.
2
Power supply (x) Total consumption of electri-
(single-phase) cal heater plus filtering
Voltage Hertz Ampere
(k)
220-240 ~
50 16
The electrical system that powers the spa must absolutely be
sized for maximum consumption (as shown in the table).
Weights
Net weight average fill
kg
~ 880
~ 260
area involved resting surface
m 2
~ 2,67
~ 3,7
Safety of use
I
The system, if installed by qualified personnel in compliance with
the provisions stated in part two of the enclosed manual, presents
no risks for the user. Safety, however, is also related to correct use,
according to the provisions in part one, while the user must assign
the operations described in part two to qualified personnel.
I
It is important to check that personnel in charge of installation and
running the system are qualified in compliance with the law provisions
in force in the Country where installation is carried out.
I
For any extra maintenance and/or repairs, we recommend that you
contact an Authorized Service Centre and use only original spare parts.

Preparations for installation

I
i
Oxia is provided with a drain, prepared as in
3, (detail B).
The Customer must make provisions for a ground drainage point of
suitable dimensions, which can be inspected for any cleaning.
I
Oxia Performance: connection must also be provided to the
drain for periodic backwash and possible emptying of the sand fil-
ter installed on the spa-pak, as well as electrical and plumbing con-
nection between the spa-pak and the spa (see the corresponding
installation manual).
CAUTION! Before preparing the ground drainage point, con-
sult the local authority for the regulations that control the
drainage of chemically treated water.
I
For periodic emptying of the spa a hose can be connected to the
drain, then remove the closure cover at the base and screw on the
provided hose coupler provided (
N.B. To open the valve, you must turn the ring nut anticlockwise
and pull it, therefore if you decide to connect the spa permanently
to the ground drainage point, we recommend you install a valve
below, bypassing the valve installed in the factory.
I
The ground drainage point must then be put into position accord-
11
(k): 230V (single-phase)
Spa-Pak
(optional)
(x): see "Electrical con-
kW Ampere kW nections pre-arrangement"
(j) (j)
(k)
3,5 0,5 (j): absorbed power
2,5
maximum
water volume
litres litres
~ 1100
average load
on area involved
kg/m
m 2 2
~ 368
i
i
3, detail B).
max. total
weight
kg
~ 1360
concentrated load
on resting surface
kg/m 2
~ 510
1, (detail 1);
