1. Installation ZMZ 0205 / ZMZ 0215
• Drill fixing holes in accordance with dimension drawing (Abb. 6)
• The coin meter can be mounted to the wall with the enclosed screws after opening
the device and dismounting the connecting covering cap.
• To secure the correct function of the coin meter, it is necessary to mount the coin
meter strictly vertical
Connection: Important! Before accessing the connection clamps, all power circles
has to be cut off.
VDE- and local regulations has to be attended
• On site, the connection has to be equiped with a switch of 3 mm break down.
• Carry the connection cords through cable sleeves
• For easy wiring the left part of connector is peelable. The terminal configuration is
printed on the terminal cover.
• Build up connection in accordance with wiring diagram (Abb. 1-5)
• While snap connector on keep secure latching in mind
• Refit terminal cover
Safety low-tension (Option „L")
While usage in humid areas the connection with a 24 V safety low-tension is suggested.
Therefore you have to install a 24 V AC cord into the humid area. A 230 V / 24 V 100 VA
power transformator for up to 4 ZMZ controls is available ex factory.
ATTENTION!
These devices are not intended for use by persons (including children) with reduced
physical, sensory or mental abilities or lack of experience and/or knowledge, unless they
are supervised by a person which is responsible for their safety or received an instruction
in how to use the device.
Children should be supervised to ensure that they do not play with the device.
Security notice
To prevent any danger to people and damage to the device, you have to avoid the ingress
of moisture e.g. for depleting coins.
