ubbink Ubiflux W300+ Installationsvorschriften Seite 106

Supply voltage [V/Hz]
Protection degree
Dimensions (w x h x d) [mm]
Duct diameter [mm]
External diameter condensate discharge [mm]
Weight [kg]
Filter class
Fan setting (factory setting))
Ventilation capacity [m /h]
3
Permissible resistance ducts system [Pa]
Rated power (excl. preheater)[W]
Rated current (excl. preheater)[A]
Max. rated current (with preheater switched on) [A]
Cos φ
Ubiflux W450
Ventilation capacity [m
3
Sound power Static pressure [Pa]
level Lw (A)
Housing emission [dB(A)
Duct "from dwelling" [dB(A)]
Duct "to dwelling" [dB(A)]
In practice, the value may deviate 1 dB(A) as a result of measuring tolerances
/h]
Ubiflux W300(+) / W400(+) / W450+
50
2 - 5
9,5
0,10
0,43
100 200
9 40 38 80 47
29.5 32.5 40.5 40.5 43.5 47.5 51.0 53.0 54.0 54.5 57.0
31.5 34.5 46.5 48.0 48.5 50.0 56.5 57.0 58.0 59.0 60.0
42.5 47.5 57.0 59.0 60.5 62.5 66.0 68.5 69.5 70.5 71.5
Ubiflux W450
230/50
IP30
677 x 765 x 564
Ø180
Ø32
38
G3 (F7 optional for supply)
1 2
100 200
5 - 15 20 - 60
11 - 18 32 - 45
0,10 - 0,18 0,30 - 0,46
6
0,43 - 0,45 0,43 - 0,45
225 300
100 84 175 240
3
300
40 - 130
80 - 105
0,70 - 0,95
0,48 - 0,50
400
150 225
8
