Application - ubbink Ubiflux W300+ Installationsvorschriften

Application

The Ubiflux W300 / W400 / W450 is a ventilation unit with heat
recovery with a maximum ventilation capacity of 300, 400 or
450 m /h and low-energy fans. Features Ubiflux:
3
• steplessly adjustable air flow rates through a control panel;
• filter indication on the appliance and the possibility for filter
indication on the multiple switch;
• a completely new intelligent frost protection system which
ensures that also at low outdoor temperatures the applian-
ce's performance remains optimal and that, if necessary, it
activates the standard preheater.
• low sound level
• comes as standard with automatic bypass valve
• constant flow control
• low energy consumption
• high efficiency
Ubiflux W300 / W400 / W450 is available in two types:
• Ubiflux"
• Ubiflux +"
Compared to the Ubiflux, the Ubiflux + has a more extensive
control board which increases the connection options.
These installation instruction describe both the standard Ubiflux
and the Ubiflux +.
The Ubiflux (+) is available in the left-handed or right-handed
Type
Ubiflux
Ubiflux +
Version types Ubiflux W300/W400/W450
Type W450 is only available in left, right version 4/0
Version L of R Position air ducts
4 top connections
Left-handed version 2 top connections & 2 bottom connections
3 top connections & 1 bottom connection
4 top connections
Right-hand version 2 top connections & 2 bottom connections
3 top connections & 1 bottom connection
4 top connections
Left-handed version 2 top connections & 2 bottom connections
3 top connections & 1 bottom connection
4 top connections
Right-hand version 2 top connections & 2 bottom connections
3 top connections & 1 bottom connection
Ubiflux W300(+) / W400(+) W450(+)
version. A left-handed version has the filters on the left behind
the filter door; a right-handed version has the filters on the right
behind the filtered door. The position of the air ducts differs for
these two versions! For the correct position of the connection
ducts and dimensions see §3.4.1 or §3.4.2. respectively.
When ordering an appliance always state the correct type; sub-
sequent conversion to a different version is not possible.
The Ubiflux comes ready to plug in with a 230 V mains plug and
a connection for a low-voltage multiple switch on the outside of
the appliance.
Note: When replacing an older model by a new Ubiflux,
do realise that the positions of the ducts "From
dwelling" and "From atmosphere" are different!
(only for type 4/0 & 3/1) Carefully check the posi-
tion of these ducts on the basis of the connection
drawings §3.4.1 and §3.4.2.
Chapter 2
Power supply Type code
Power plug 4/0 L
Power plug 2/2 L
Power plug 3/1 L
Power plug 4/0 R
Power plug 2/2 R
Power plug 3/1 R
Power plug 4/0 L+
Power plug 2/2 L+
Power plug 3/1 L+
Power plug 4/0 R+
Power plug 2/2 R+
Power plug 3/1 R+
5
