Fitting & operation information:
Please refer to the instruction diagrams:
Pushchair
1-
Rear axle
2-
assembly
3-
Rear wheel
4-
5-
Front wheel
6-
7-
Front wheel
8-
swivel lock
9-
Brake
10-
11-
Harness
12-
13-
14-
15-
16-
Footmuff
17-
(Sold separately)
Backrest
18-
19-
Calf support
20-
21-
Basket
22-
Access zip
23-
Hood
24-
25-
3
Opening:
Release auto lock (a) then pull the handle upward (b) until a "click" is heard
(c) and the hinge is locked in place.
Check the chassis has locked in place.
Fitting:
Removing:
Fitting:
Removing:
Fitting:
Removing:
Applying:
Releasing:
Applying:
Releasing:
Opening:
Closing:
Adjusting the strap length:
Slide the strap adjustor to suitable length (a, b & c)
Adjusting the shoulder strap position:
Removing:
Push the shoulder strap retainer through the backrest (a).
Push the crotch strap retainer through the seat (b).
Rotate the "C" clip to expose its opening (c) and slide the waist strap out of
clip (d).
Refitting is a reversal of this procedure.
Fitting:
Open the harness, refer to step 12.
Remove the chest pads, crotch pad & headhugger (a)
Push the harness straps through the footmuff liner (b).
Attach the footmuff fabric fasteners to the rear of the backrest (c).
Fit the chest pads, crotch pad & headhugger then close the harness (Refer
to step 13).
Lowering:
Raising:
Lowering:
Raising:
Removing:
Refitting is a reversal of this procedure.
Opening:
Fitting:
Push the brackets onto the mounts on the chassis (a).
Attach the fabric fasteners to the inside of the seat unit (b).
Attach the fabric fasteners to the outside of the seat unit (c & d).
Removing is a reversal of this procedure.
Opening:
