1. Keyed hole
3. Remove the decal that covers the keyed hole in the back of
the housing (Figure 5).
1. Decal
4. Ensure that the handle of the chute control rod points
upward (Figure 6), and insert the rod into the keyed hole
in the back of the housing.
Figure 4
2. Bracket
Figure 5
2. Keyed hole
g013477
1. Handle on the chute control rod
5. Firmly push the rod into the keyed hole in the back of the
housing until it snaps into place.
6. Move the handle on the chute control rod to ensure that it
moves in the same direction as the chute
g013453
5
Figure 6
(Figure
Figure 7
g021775
7).
g013457
