When connecting to COMPONENT VIDEO (INPUT5)
COMPONENT
INPUT5
VIDEO
Y Pb/Cb Pr/Cr
Connect the Y signal to the Y jack, the P
P /C jack, and the P /C signal to the P
B B R R
Note
The Plasma Display and this Video Card are designed to support
component video signals with standard, stable signal levels and
sync signals. As a result, some image disruption may be
generated during use of various special trick play functions on
video components.
Connection of G ON SYNC analog RGB source
Make G ON SYNC connections for a component with
output that has the synchronization signal layered on top
of the green signal.
When connecting to ANALOG RGB IN (INPUT1)
INPUT1
ANALOG RGB OUT ANALOG RGB IN
(D-Sub) (D-Sub)
On-screen setup is necessary after connection.
Please see pages 18 to 21.
When connecting to ANALOG RGB (INPUT5)
[Connections for PDA-5003]
/C signal to the
On-screen setup is necessary after connection.
B B
/C jack.
Please see pages 18 to 21.
R R
Note
When making G ON SYNC connections, do not make any
connections to the VD or HD jacks. If connections are made, the
picture may be not displayed normally.
When connecting to COMPONENT VIDEO (INPUT5)
[Connections for PDA-5004]
Connect the G ON SYNC signal to the Y jack, the B signal
to the P
On-screen setup is necessary after connection.
Please see pages 18 to 21.
Installation and Connections
INPUT5
ANALOG RGB
G(ON SYNC) B R HD (H/V SYNC) VD
COMPONENT
INPUT5
VIDEO
Y Pb/Cb Pr/Cr
/C jack, and the R signal to the P
B B
/C jack.
R R
