Tempco RF Bedienungsanleitung Seite 34

RF Installation - Master
Your main zone programmer can manage up to 3 Masters.
(Maximum 12 zones by Masters).
Zone = 1 thermostat.
See described example of Installation, part 1.3 for more details.
Once the Master is installed and linked you will have the possibility
to view its configuration (Number of zone used...)
You will have also the possibility to erase it.
RF Installation - One Zone
Your main zone programmer can manage up to 9 one zone
receivers.
st
1 Page
a) First of all you must link the thermostat with the receiver, to do
this put the receiver in "RF init" mode by pressing the Receiver
push button during 5sec, the Green RF LED should lit up (fixed)
indicating that the Receiver is now in radio configuration mode
waiting for a clock configuration address. (In all the cases check
the receiver leaflet for more explanation)
...
34
rd
3 page
