3.3 Zone submenu
On this submenu you can see all zones of your installation.
Current working
mode
Heating or
cooling indicator
First of all, for a better understanding after installation you should
rename the zones.
To make this operation press on the button "Zone settings" to show
this screen:
3.3.1
Zone Settings
a)
Rename function
Press on the "Rename" button, now you will have the possibility to
change the default name "TH" by pressing on the button, then you
can choose a name in the list by using the arrow buttons.
Repeat these rules to change the number (zero for blank).
Valid your adjustment by pressing on the validation button.
The zone number is always displayed on this menu to help you to
know which zone(s) on your Master is controlled by the thermostat.
1)
15
Number of zone
Zone settings
Set point, room, floor
temp temperature
To jump to the next
zone
2)
