Presentation, Main display

2
Actual
working
mode
Sensor use
for
regulation
Room
temperature
Setting
menu
*
The logo will be in movement to show water circulation in the zone.
The logo could be different following the brand of your device.
Quick access description:
- Press on the sensor logo to view the others sensors connected to
your unit and choose the value which will be displayed on the main
screen by pressing on it. (Highlighted in green)
You must connect:
A Floor sensor to view the temperature of floor.
A RH humidity sensor to view residual humidity.
- Press on the temperature on the middle of the screen to have a
quick access to the current setting and working mode.
Information symbol
See part 5.2
12
Working
mode. *
Zone menu
