Product Description - Sharp LL-T17A3 Bedienungsanleitung

1 2
3
1. MENU button ............................ This button is used to pop-up, select and close the OSD (On Screen
2. / MODE button ..................... When the OSD Menu is displayed:
3. buttons ............................. When the OSD Menu is displayed:
4. Power button ............................ Pressing this button turns the power on. (After turning the power on, it
5. Power LED ............................... This LED is lit green when in use and orange when in power-saving
6. Speakers .................................. Audio entering via the monitor and the external device connected to
7. Audio input terminal ................. A computer's audio output terminal can be connected here. The audio
8. Power terminal ......................... The AC adapter is connected here.
9. Analog RGB input terminal ...... The analog signal cable is connected here.The analog signal cable
10. Security lock anchor ................ By connecting a security lock (commercially available) to the security
11. Ventilation openings ................ Note: Never block the ventilation openings as this may lead to
12. Lock disable button .................. This button is used when folding back the display section.

Product description

6
4
5
Display) Menu.
This button is used to select menu options.
When the OSD Menu is not displayed:
This button is used to set COLOR MODE.
These buttons are used to increase or decrease the value of a
selected option.
When the OSD Menu is not displayed:
These buttons are used to adjust backlight brightness and speaker
volume.
may take a little time before the screen displays.)
Press the button again to turn the power off.
mode.
the monitor can be heard.
cable included should be used.
included should be used.
lock anchor, the monitor is fixed so that it cannot be transported.
The security slot works in conjunction with Kensington Micro Saver
Security Systems.
overheating inside the monitor and result in malfunction.
9
12 7
8 9
11
10
