Cimbali TOUCH REVOLUTION Übersetzung Der Originalanleitung Seite 6

Caldaia - Service boiler - Chaudière
Heizkessel - Caldera - Caldeira
Boiler caffè - Coffee boiler
Chauffe-eau, café - Boiler Kaffee
Calentador café - Boiler do cafè
For UK MARKET ONLY (Ref. PSSR 2000)
The service boiler must be completely
changed at periods no greater than 5 years.
POWER INSTALLED
SUPPLY POWER
220-240V 50Hz 4,8 - 5,7 kW
220V 60Hz 4,8 kW
380-415V3N 50Hz 4,8 - 5,7 kW
Machine
380V3N 60Hz 4,8 kW
220-240V3 50Hz 4,8 - 5,7 kW
220V3 60Hz 4,8 kW
P T Fluido - Fluid - Fluide
max max
Flüssig - Fluido - Fluido
[ bar ] [ °C ]
acqua/vapore - water/steam - eau/vapeur
2,5
133°C
Wasser/Dampf - agua/vapor - água/vapor
bar
acqua - water - eau
12
133°C
Wasser - agua - água
bar
SUPPLY
LINE
CABLE
POWER
SECTION
24A min. 3 x 4 mm
2
12A min. 5 x 1,5 mm
2
19A min. 4 x 2,5 mm
2 185 (7.28)
248 (9.8)
370 (14.6)
110 (4.33)
ø120(4.7)
ø120 (4.7)
POWER
IV
Capacità - Capacity - Capacitè
Fassungsvermögen - Capacidad - Capacidade
1.3
0.7
294 (11.6)
620 (24.4)
Weight
pounds
INSTALLED LINE
[ L ]
Kg 79
174
SUPPLY CABL
