rECommENDED FirE-
EXTiNGUiSHiNG DEViCES
For guidance on the most suitable type of ex-
tinguisher, refer to the table below:
Dry
materials
Water YES
Foam YES
Powder YES*
CO YES*
2
YES* Use only if more appropriate extinguishers
are not at hand or when the fire is small.
WarNiNG
This table contains general instructions in-
tended to be used as guidelines for users.
Contact the manufacturer for details of the
applications of each type of extinguisher.

GLoSSarY

air release valve
A special fitting that allows you to control the
flow rate of discharging air
Bead
The edge of the tyre that remains in contact
with the rim when the tyre is installed.
Bead breaking
Operation that serves to detach the tyre bead
from the edge of the rim
Bead seating
This operation is performed during inflation.
Bead seating assures that the tyre bead and the
edge of the rim are perfectly positioned.
Tubeless
A tyre without an inner tube.
Tubeless tyre inflation (FI)
Inflation system for tubeless tyres.
32
Electrical
Flammable
equip-
liquids
ment
NO NO
YES NO
YES YES
YES YES
GENEraL ELECTriCaL
LaYoUT
Fig. 33
QS1 Direction reverser
XS1 Power supply socket
M1 Motor
C1 Condenser
R1 Resistance

ComPrESSED air LaYoUT

Fig. 35
1 Quick coupling
2 Regulator filter unit
3 Inflation foot pedal
4 Inflation gun
5 Air release button
6 Pressure gauge
8 Table top valve
9 Bead breaker valve
10 Bead breaker cylinder
11 Rh table top cylinder
12 Lh table top cylinder
18 Swivel valve
19 Air blast valve
20 Tank
21 Relief valve
26 Compressed air motor
31 5V - 3P motor air valve
32 Inflating regulator unit
33 Automatic distributing device for
rapid air discharge
