3 DEPTH FUNCTIONS
3.4.

Depth functions (optional)

To change between Log and Depth information press MODE. This function will
display depth in metres, feet or fathoms. To change unit see 4.2.6. A depth
sounder measures the time it takes for a sound pulse transmitted from the
transducer, to bounce on the bottom and be received by the transducer again.
The strength of the sound pulse decreases with the depth and is also affected
by temperature and pollution in the water. A soft bottom with a lot of vegetation
will also decrease the strength of the echo, which can result in poor reception
by the receiver. If no echo is registrated the depth reading will be three dashes
i.e. no echo.
3.4.1.

Boat speed

To view boat speed press UP or DOWN until the text BSP is displayed. The
unit (Knots or Miles/h) is selectable in calibration, see 4.2.4.
3.4.2.

Shallow alarm

To get to the shallow alarm function, press UP or DOWN until the text
SHALLOW is displayed. To change the alarm value, unlock with KEY,
increase/decrease the value with UP/DOWN, move to the next figure with
MODE button and lock the value again with KEY.
3.4.3.

Deep alarm

To get to the deep alarm function press UP or DOWN until the text
DEEP is displayed. To change the alarm value, unlock with KEY,
increase/decrease the value with UP/DOWN, move to next figure
with MODE button and lock the value
again with KEY. The alarm is activated.
3.4.4.

Silencing an alarm

If a shallow alarm limit is reached the instrument will display depth on the top row
and the alarm limit flashing on the bottom row. To silence the alarm press any
button or steer the boat to deeper water. The alarm will be automatically activated
again if the boat is taken to deeper water ( 2 m more than the limit).
3.4.5.

Activate / Deactivate an alarm

To activate / deactivate an alarm, go to the alarm function an press UP and
DOWN together. If an alarm is active the present alarm value is displayed
together with the text SHA or DEP. If the alarm is deactivated the text SHALLOW
or DEEP is displayed instead. The alarm value is stored in the memory even if
the alarm is deactivated.
