3 LOG FUNCTIONS

3.2. Log functions
3.2.1.

Boat speed

The main functions displays
the boat speed. The unit
(Knots or Miles/h) is
selectable during calibration,
see 4.2.4.
3.2.2.

Water temperature

To view water temperature press UP or DOWN until the
text TMP is displayed. The water temperature can be
displayed in Celsius or Fahrenheit.
To change unit, see 4.2.8.
3.2.3.

Trip distance

To view the trip distance press UP or DOWN until the text
TRP is displayed. To clear the trip distance press UP and
DOWN together. Range: 0-199.99 Nm.
3.2.4.

Total distance

To view the total distance press UP or DOWN. Total
distance is not possible to clear and will be stored in the
instruments permanent memory.
Range. 0- 19999.99 Nm.
3.2.5.

Depth

To view depth press UP or DOWN until the text DPT is
displayed. The depth function is only displayed if
instrument type is set to combi. To change instrument
type, see 4.2.3.

3.3. Illumination

The LCD and push buttons have three levels of
illumination. To turn on light, press MODE until the text Lit
appears. Change level with UP or Down and lock
selection with KEY.
