4 CALIBRATION
4.2.7.

C16 Adjusting depth (0.00 ADJ)

It is possible to adjust the depth reading plus/minus 99.9 m. This feature
makes it possible to get the reading from either the keel or the water surface.
Example: Your boat has a draft of two metres and the transducer is
mounted one half metre below the water surface.
1. If you want the reading from the water surface you have to add 0.5 m
2. If you want the reading from the keel you have to subtract 1.5 m
Note! Calibration should be carried out in the same unit chosen for display.
4.2.8. C17 Unit for temperature (Unit °C)
The unit for temperature is selectable between Celsius (°C) or Fahrenheit (°F).
To change unit press KEY and select unit with UP or DOWN and confirm with
KEY.
4.2.9. C18 Temperature adjustment (0°C TMP)
The temperature reading can be adjusted for accurate reading plus/minus nine
degrees.
4.2.10. C19 Unit for trip and total distance (Unit NM)
The unit for distance is selectable between Nautical Miles (NM), Kilometres
(KM) and Miles (MI). To change unit press KEY and select unit with
UP or DOWN and confirm with KEY.

4.3. Customise your display

The two main functions have one "empty" sub function. One sub function from the
other main function group can be moved into this empty space. For example,
the trip distance can be moved to the depth group. To do that, go to the trip
function and press KEY and MODE together, the display is flashing.
Go to the depth functions by pressing MODE and lock with KEY.
It is possible to move two functions, one under speed and one under depth.
The last customised display is the display the instrument starts up in,
after power on.
If you want the instrument to start up displaying speed and trip after power on
go to the trip function under speed and press KEY and MODE together.
The display will be flashing, lock with KEY.
