INSTALLATION LAYOUT

4 2
C
COMPONENTS
Motor
1
2 Control unit
Transmitter
3
Receiving module
4
Photocells
5
Flashing light
6
LENGTH OF THE CABLE
Power supply (230V)
230V motor power supply
24V motor power supply
Photocells (TX)
Photocells (RX)
Key switch
Safety edges
Flashing light
Antenna (integrated into the flashing light)
ECO-LOGIC (accumulator unit)
ECO-LOGIC (solar panel)
6
1 D
ADDITIONAL ACCESSORIES
Key switch
A
B Pillar photocells
Pillar-mounted digital radio switch
C
Safety edges
D
ECO-LOGIC system (only with CALYPSO-24V and CITY2+BC)
E
< 10 metres
3G x 1,5 mm 2
4G x 1,5 mm 2
2G x 1,5 mm 2
2 x 0,5 mm
2
4 x 0,5 mm
2
2 x 0,5 mm
2
2 x 0,5 mm
2
2 x 1,5 mm 2
RG174
2 x 1,5 mm 2
2 x 1 mm
2
- 10 -
5
1
3
from 10 to 20 metres
3G x 1,5 mm 2
4G x 1,5 mm 2
2G x 1,5 mm 2
2 x 0,5 mm
2
4 x 0,5 mm
2
2 x 0,5 mm
2
2 x 0,5 mm
2
2 x 1,5 mm 2
RG174
-
-
A
from 20 to 30 metres
3G x 2,5 mm 2
4G x 2,5 mm 2
2G x 2,5 mm 2
2 x 0,5 mm
2
4 x 0,5 mm
2
2 x 0,5 mm
2
2 x 0,5 mm
2
2 x 1,5 mm 2
RG174
-
-
