One-point calibration

11
One-point calibration is recommended for measurements with very thin coa-
ting thicknesses.
Switch the device to calibration mode as described in step 9 and keep the
"ESC" key pressed until the display shows the measuring mode.
Take the following steps to perform a one-point calibration:
1. Perform zero calibration as described in Step 10.
2. A calibrating foil corresponding with the estimated coating thickness to be
measured is placed on the uncoated base pattern.
3. Place the measuring head vertically.
4. Put down the measuring device after measuring.
5. Adjust the thickness of the calibrating foil on the display using the keys
" " and " "
6. Repeat steps 3 to 4 several times
7. Press the "zero" key to accept the calibration
8. One-point calibration is complete. Disable the calibration mode again

Two-point calibration

12
Two-point calibration is recommended for measurements on rough surfaces.
Switch the device to calibration mode as described in step 9 and keep the
"ESC" key pressed until the display shows the measuring mode.
Take the following steps to perform a two-point calibration:
1. Perform zero calibration as described in Step 10.
2. Perform one-point calibration as described in step 11. However, use a
calibrating foil that is thinner than the estimated coating thickness to be
measured.
3. Repeat step 2 with a calibrating foil that is thicker than the estimated coa-
ting thickness to be measured.
4. Press the "zero" key to accept the calibration
5. Two-point calibration is complete. Disable the calibration mode again
