Intended Use; Parts Description; Technical Data - LIVARNOLUX IAN 280200 Montage-, Bedienungs- Und Sicherheitshinweise

Intended use

The product is intended to illuminate outdoor areas without electrical
connection, e.g. garden sheds etc. This product is only intended for
private use and is not suitable for commercial use or for use in other
applications.
Not suitable for ordinary lighting in household room
illumination.
This product is suitable for extreme temperature up to -21°C.

Parts description

Main unit
1
LED spotlight
2
Motion detector
3
Screw (Ø 3.6 x 30 mm)
4
Mounting plate
5
Wall plug (Ø 6 mm)
6

Technical Data

Operating voltage:
Operating batteries: 4 x 1.5 V
LED:
Motion detector:
Degree of protection: IP44 (splash-proof)
7
8
9
10
11
4 x 1.5 V (direct current)
(direct current), size C
2 x 4 W (LEDs not replaceable)
Range: max. 8 m, detection angle:
approx. 140° horizontal, approx. 90° vertical
Cap
Battery compartment cover
Battery compartment
Rotary control LUX
Rotary control TIME
GB 7
