Ventilate:
The "Ventilate" function (1) allows the display and control of the status of a KNX ventilation
controller.
In the input field (2), it is possible to specify the group address for controlling the fan and,
in the input field (3), it is possible to enter the group address for the feedback of the
currently set fan step.
One of the two group addresses can be selected for the initialisation (4) of the Smart Visu
Server on its system start.
The function possesses the following individualisation options within the icon library (5).
KNX function
Ventilate
SV- SERVER / SV-SERVER-INT
5
Figure 81: Parameters of the "Ventilate" function
Selection of the icon library
in SV-Control
Table 39: Display of the "Ventilate" function
1
2
3
4
Operating and display element
in SV-Home
