Produktdokumentation / Product Documentation
Smart Visu Server
SV-SERVER
SV-SERVER-INT
ALBRECHT JUNG GMBH & CO. KG
Volmestraße 1
D-58579 Schalksmühle
Tel: +49.23 55.8 06-0
Fax: +49.23 55.8 06-2 04
kundencenter@jung.de
www.jung.de
Service Center / Service Centre
Kupferstr. 17-19
44532 Lünen
Germany
31.03.2016

Werbung

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für Jung Smart Visu Server

  • Seite 1 Produktdokumentation / Product Documentation Smart Visu Server SV-SERVER SV-SERVER-INT ALBRECHT JUNG GMBH & CO. KG Volmestraße 1 D-58579 Schalksmühle Tel: +49.23 55.8 06-0 Fax: +49.23 55.8 06-2 04 kundencenter@jung.de www.jung.de Service Center / Service Centre Kupferstr. 17-19 44532 Lünen Germany...
  • Seite 2: Inhaltsverzeichnis

    INBETRIEBNAHME DES SMART VISU SERVER ..........3 Bestimmungsgemäßer Gebrauch ................... 3 Produkteigenschaften ...................... 3 Lieferumfang ........................4 Technische Daten ......................4 Geräteaufbau, Funktion ....................5 Systeminformation......................6 Montage, Inbetriebnahme ....................7 1.7.1 SV-Home – Bedienoberfläche ................8 1.7.2 SV-Control – Projektierungsoberfläche ..............9 Gewährleistung .......................
  • Seite 3 Setting the system time and date ............... 120 7.6.3 Server update ..................... 120 SV-HOME ...................... 122 UPDATE OF THE SMART VISU SERVER ............ 123 Reading out the software version ................123 Performing a system update ..................123 APPENDIX ..................... 124 10.1...
  • Seite 4: Inbetriebnahme Des Smart Visu Server

    1 Inbetriebnahme des Smart Visu Server Sicherheitshinweise WARNUNG Bei Nichtbeachten der Anleitung können Schäden am Gerät, Brand oder andere Gefahren entstehen. Diese Anleitung ist Bestandteil des Produktes und muss beim Endkunden verbleiben. Einbau und Montage elektrischer Geräte dürfen nur durch Elektrofachkräfte erfolgen. Dieses Produkt ist nur zur Verwendung in trockenen Räumen bestimmt.
  • Seite 5: Lieferumfang

    Philips und Hue sind eingetragene Warenzeichen der Koninklijke Philips Electronics NV. Dieses Produkt enthält Open-Source-Softwarekomponenten, die den Bedingungen der Urheberrechtsvermerke und/oder Lizenzvereinbarungen Dritter unterliegen. Die Lizenz- informationen befinden sich auf dem Smart Visu Server. 1.4 Technische Daten Nennspannung: DC 12 V SELV Leistungsaufnahme: Typ.
  • Seite 6: Geräteaufbau, Funktion

    1.5 Geräteaufbau, Funktion Abbildung 1: Geräteaufbau des Smart Visu Servers (1) USB-Schnittstelle Für Softwareupdates und zur Datensicherung (2) Ethernet-Schnittstelle Zum Anschluss an das lokale Netzwerk (3) Spannungsversorgung Nur das Netzteil aus dem Lieferumfang (4) Status-LED Zeigt den aktuellen Status des Servers an (5) Reset-Taste Reset und Update (6) Entladeschutz...
  • Seite 7: Systeminformation

    1.6 Systeminformation Der Smart Visu Server dient der Visualisierung und Bedienung eines am gleichen Netzwerk angeschlossenen KNX-Systems über Smartphone, Tablet, Laptop oder PC und der Steuerung von Philips Hue Systemen (SV-Home). Zur Funktion ist ein lokales Netzwerk erforderlich. Die Verbindung zum KNX erfolgt über die KNX-IP-Schnittstelle. Die Verbindung zum Philips Hue System erfolgt über die Philips Hue Bridge.
  • Seite 8: Montage, Inbetriebnahme

    Für den Zugriff auf SV-Home und SV-Control wird ein aktueller HTML5-fähiger Browser (Eingabegerät) benötigt. Smart Visu Server, Schnittstelle, Netzwerk-Router (DHCP aktiv) und Eingabegerät müssen Teil des selben Netzwerkes sein. Der Smart Visu Server erwartet bei der Inbetriebnahme die Vergabe einer IP-Adresse per DHCP.
  • Seite 9: Sv-Home - Bedienoberfläche

    1.7.1 SV-Home – Bedienoberfläche Die SV-Home ist die integrierte Weboberfläche des Smart Visu Servers zur Visualisierung, Zustandsanzeige und Bedienung der KNX-Anlage und des Philips Hue Systems. Automatisch wird die SV- Home aus der erstellten Konfiguration im SV-Control generiert. Für den Zugriff auf SV-Home wird ein aktueller HTML5-fähiger Browser (Eingabegerät) benötigt.
  • Seite 10: Sv-Control - Projektierungsoberfläche

    1.7.2 SV-Control – Projektierungsoberfläche Dieses Unterkapitel dient dazu den Aufbau der Projektierungsoberfläche kennenzulernen. Im nachfolgenden Kapitel werden die Funktionen und die genaue Vorgehensweise für die Projektierung detailliert beschrieben. Das SV-Control ist das integrierte, webbasierte Inbetriebnahmetool des Smart Visu Servers. Des Weiteren kann hier die Systemkonfiguration vorgenommen werden. Für den Zugriff auf SV-Control wird ein aktueller HTML5-fähiger Browser (Eingabegerät) benötigt.
  • Seite 11: Gewährleistung

    1.8 Gewährleistung Die Gewährleistung erfolgt im Rahmen der gesetzlichen Bestimmungen über den Fachhandel. Das CE-Zeichen ist ein Freiverkehrszeichen, das sich ausschließlich an die Behörden wendet und keine Zusicherung von Eigenschaften beinhaltet. SV- SERVER / SV-SERVER-INT 10 / 150...
  • Seite 12: Sv-Control

    2 SV-Control In diesem Kapitel wird die Konfiguration und die Inbetriebnahme des Smart Visu Servers über das SV-Control detailliert beschrieben. 2.1 Registerkarte Projekt Die Registerkarte „Projekt“ dient als Startseite des SV-Controls. In dieser kann die gewünschte Sprache eingestellt (1), die Projektierung gestartet (2), das gesamte Projekt gesichert (3) oder ein zuvor gesichertes Projekt wiederhergestellt werden (4).
  • Seite 13: Projekt Wiederherstellen

    “ (4) kann ein vorheriger Projektstand wiederhergestellt werden. Dieser Vorgang kann einige Minuten in Anspruch nehmen. INFORMATION Der Smart Visu Server kann ausschließlich ein Projekt verwalten. Wird durch die Schaltfläche „Wiederherstellen“ ein Projekt eingespielt, wird das ggf. vorhandene Projekt gelöscht.
  • Seite 14: Produktdokumentation

    Profil „Benutzer“ aktivieren Durch optionale Vergabe eines Passwortes im Eingabefeld (1) kann ein Administrator- passwort festgelegt werden. Um das Profil „Benutzer“ zu aktivieren und das Passwort zu übernehmen ist die Schaltfläche „ “ (2) zu betätigen. Administrator aktiv: Nach optionaler Vergabe eines Passwortes wird das Profil „Benutzer“...
  • Seite 15: Knx

    Fa. Jung: KNX IP-Schnittstelle Art.-Nr.: IPS 200 REG Fa. Jung: KNX IP-Router Art.-Nr.: IPR 200 REG Dem Smart Visu Server muss die aktuelle IP-Adresse der KNX-IP Datenschnittstellen mitgeteilt werden. Am einfachsten ist diese aus der ETS-Konfiguration des Gerätes (statische IP Adresse aktiv) oder aus dem Netzwerk-Router (DHCP aktiv) zu ermitteln. Die ermittelte IP-Adresse der KNX-IP Datenschnittstellen ist im Feld „KNX-IP-Gateway“...
  • Seite 16: Knx-Opc-Projektdatei Importieren

    Den Import der OPC-Projektdatei können Sie durch Betätigung der Schalfläche „ “ (1) veranlassen. Im Anschluss werden Sie aufgefordert die Datei auszuwählen und an den Smart Visu Server hochzuladen. Nach dem Hochladen werden alle importierten Gruppenadressen mit dem Gruppennamen, der Gruppenbeschreibung der Datentyplänge in einer Liste unterhalb der Importfunktion aufgeführt.
  • Seite 17: Hue

    Philips Hue Bridge mit dem Smart Visu Server gekoppelt werden soll, können Sie die IP-Adresse manuell editieren. Zur Kopplung der Bridge mit dem Smart Visu Server muss die Pairing Taste der Bridge zur Authentifizierung betätigt werden (1). Ein erfolgreiches Pairing wird durch einen grünen Haken ( ) am Ende der Eingabezeile (3) visualisiert.
  • Seite 18: Hue Leuchtmittel Importieren

    2.3.2 Hue Leuchtmittel importieren Die im Hue System konfigurierten Leuchtmittel werden anschließend unterhalb mit ihrem Namen und dem aktuellen Status aufgelistet. Es können nur Leuchtmittel aufgelistet werden, die in der Bridge konfiguriert sind. Durch Betätigung der Schalfläche „ “ (1) können ausgewählte Leuchtmittel als Hue- Funktion hinzufügt werden.
  • Seite 19: Bereich & Funktionen

    2.4 Bereich & Funktionen Ein Bereich ist eine Gruppierung von Funktionen und Aktionen zur Visualisierung im SV- Home unter einem individuellen Bereichsnamen. Zur besseren Wiedererkennung kann jedem der bis zu 24 Bereiche ein Symbol zugewiesen werden. Bereiche ermöglichen es, die bis zu 240 Funktionen und 250 Aktionen beliebig z.B. räumlich und/oder nach Gewerken zu gruppieren.
  • Seite 20: Neuen Bereich Erstellen

    2.4.1 Neuen Bereich erstellen Die bis zu 24 Bereiche können individuelle Namen, Symbole aus der SV-Server-Bibliothek oder zusätzliche Beschreibungen erhalten. Der „Benutzer“ und der „Administrator“ besitzen innerhalb der Spalte „Bereiche“ identische Zugriffsrechte. Um einen neuen Bereich zu erstellen, geben Sie in der Spalte „Bereiche“ (1) Ihren Namen des neuen Bereiches ein und betätigen Sie anschließend die Schaltfläche „...
  • Seite 21: Bereiche Bearbeiten Oder Löschen

    2.4.2 Bereiche bearbeiten oder löschen Um einen bestehenden Bereich zu bearbeiten oder zu löschen muss dieser ausgewählt sein. Innerhalb der Spalte „Bereiche“ werden alle vorhandenen Bereiche aufgeführt. In der Spalte „Eigenschaften“ kann dem ausgewählten Bereich ein alternatives Symbol durch Betätigung des aktuell ausgewählten Symbols „ “ (3) zugewiesen, der Name des Bereichs editiert (4) und unterhalb eine Beschreibung (5) ergänzt werden.
  • Seite 22: Neue Funktion Erstellen

    2.4.3 Neue Funktion erstellen Eine Funktion entspricht z.B. einer KNX-Funktion, die ggf. mehrere Gruppenadressen umfasst. Die bis zu 240 Funktionen können individuelle Namen, Symbole aus der SV- Server-Bibliothek oder zusätzliche Beschreibungen erhalten. Jede Funktion kann keinem, einem oder mehreren Bereichen zugeordnet werden. INFORMATION Um alle Funktionen erstellen zu können, müssen Sie Administratorrechte besitzen Zugriff als Administrator...
  • Seite 23 Zugriff als Benutzer neue KNX- Web-Funktionen erstellen können, müssen Administratorrechte besitzen (siehe Kapitel 2.1.5). Abbildung 16: Zugriffsrechte des Benutzers SV- SERVER / SV-SERVER-INT 22 / 150...
  • Seite 24: Knx-Funktionen Konfigurieren

    2.4.4 KNX-Funktionen konfigurieren Damit KNX-Funktionen genutzt werden können, wird die erfolgreiche ETS-Inbetriebnahme des KNX Systems und Deklaration des KNX-IP-Gateways im SV-Control vorausgesetzt. Zugriff als Administrator oder Benutzer Der „Benutzer“ und der „Administrator“ besitzen innerhalb der Spalte „Funktionen“ unterschiedliche Zugriffsrechte auf KNX-Funktionen. Zugriff Benutzer Administrator...
  • Seite 25 Helligkeitswert Helligkeitswert 8 Bit 8 Bit 5.001 5.001 Rückmeldung Helligkeitswert Helligkeitswert 8 Bit 8 Bit Grün Grün 5.001 5.001 Rückmeldung Helligkeitswert Helligkeitswert 8 Bit 8 Bit Blau Blau 5.001 5.001 Rückmeldung 1 Bit Schalten 1 Bit Schalten 1.001 Rückmeldung 1.001 1 Bit Langzeit 1.008...
  • Seite 26 Status Staus 1 Bit Heizen / Kühlen Heizen / Kühlen 1.001 Lüfter Modus 1 Bit Lüfterstufe 8 Bit Belüftung 1.006 Rückmeldung 5.010 Betriebsmodus Betriebsmodus 8 Bit Betriebsmodus 8 Bit (KNX Konform) Umschaltung 20.102 Rückmeldung 20.102 Klima 16 Bit Soll-Temperatur 16 Bit Basis Sollwert Basis Sollwert 9.001...
  • Seite 27 8 Bit Szene ausführen Szenennummer 18.001 Szene Szene ausführen & 8 Bit Szenennummer überschreiben 18.001 1 Bit Anzeige 1 Bit Status ---- z.B. (Bool) Rückmeldung 1.001 8 Bit Anzeige 1 Byte Wert ---- z.B. (0.. 100 %) Rückmeldung 5.001 16 Bit Anzeige 2 Byte Wert ----...
  • Seite 28 2.4.4.1 Schalter / Dimmer Der Funktionstyp „Schalter / Dimmer“ kann wahlweise durch vier KNX-Funktionen abgebildet werden. Schalter : Die Funktion „Schalter“ (1) ist die Standard KNX-Funktion zum einfachen Ein-/ Ausschalten von Schaltaktoren. In der Funktion „Schalter“ kann eine Gruppenadresse zum Schreiben von Statusänderungen „Schalten“...
  • Seite 29 An / Aus: Die Funktion „An / Aus“ ist zustandslos (ohne Rückmeldung) und eignet sich zum gezielten Auslösen eines Schaltsignals (z.B. ausschließlich Ausschalten). Es kann eine Gruppenadresse „An / Aus“ (2) zum Schreiben des im Eingabefeld „Wert“ (3) festgelegten Wertes konfiguriert werden. Abbildung 19: Parameter der Funktion „An / Aus“...
  • Seite 30 Dimmer: Die Funktion „Dimmer“ (1) dient der einfachen Steuerung von Dimmaktoren. Es kann eine Gruppenadresse „Schalten“ (2) und / oder „Helligkeitswert“ (4) zum Schalten bzw. Schreiben eines neuen Helligkeitswertes konfiguriert werden. Zum Lesen der Rückmeldung können analog die Gruppenadressen „Schalten Rückmeldungen“ (3) und „Helligkeitswert Rückmeldung“...
  • Seite 31 RGB: Die Funktion „RGB“ (1) ist die KNX- Funktion zum Steuern von RGB Dimmaktoren. Mit der Gruppenadresse z.B. „Helligkeitswert Rot“ (2) kann der aktuelle Helligkeitswert des roten Farbkanals auf den Bus geschrieben werden. Zum Lesen der aktuellen Helligkeit des roten Farbkanals kann die Gruppenadresse „Helligkeitswert Rot Rückmeldung“...
  • Seite 32 2.4.4.2 Motor Der Funktionstyp „Motor“ kann wahlweise durch eine von drei KNX-Funktionen abgebildet werden. AUF/AB/STOP: Die Funktion „AUF/AB/STOP“ (1) ist die KNX-Funktion zum einfachen Steuern motorischer Antriebe ohne Rückmeldeobjekte. Durch die Gruppenadressen „Langzeit“ (2) und „Kurzzeit“ (3) kann der motorische Antrieb angesteuert werden. Abbildung 22: Parameter der Funktion „Auf/Ab/Stop“...
  • Seite 33 Rollade / Markise: Die Funktion „Rollade / Markise“ (1) ist die KNX-Funktion zum Steuern motorischer Rollläden/Markisen mit Positionsvorgabe. Durch die Gruppenadressen „Langzeit“ (2), „Kurzzeit“ (3) und „Vorgabe Position“ (4) kann der motorische Antrieb angesteuert werden. Zum Lesen der Position kann die Gruppenadresse „Position Rückmeldung“ (5) konfiguriert werden.
  • Seite 34 Jalousie: Die Funktion „Jalousie“ (1) ist die KNX-Funktion zum Steuern motorischer Jalousien mit Positions- und Lamellenvorgabe. Durch die Gruppenadressen „Langzeit“ (2), „Kurzzeit“ (3), „Vorgabe Position“ (4) und „Vorgabe Lamelle“ (5) kann der motorische Antrieb angesteuert werden. Zum Lesen der Positionen können die Gruppenadressen „Position Rückmeldung“ (6), und „Lamelle Rückmeldung“...
  • Seite 35 2.4.4.3 Klima Die Funktionsgruppe „Klima“ kann wahlweise durch fünf verschiedene KNX-Funktionen abgebildet werden. Status Heizen/Kühlen: Die Funktion „Status Heizen/Kühlen“ (1) ist die KNX- Funktion zum Anzeigen der aktuellen Betriebsart. Zusätzlich zum Lesen der Gruppenadresse „Heizen/Kühlen“ (2) kann durch Definition der Initialisierungsadresse (3) der aktuelle Status der Funktion auch beim Systemstart abgefragt werden.
  • Seite 36 Belüftung: Die Funktion „Belüftung“ (1) ist die KNX- Funktion zur Anzeige von Lüftungsanlagen über 1 Byte Werte. Durch die Gruppenadresse „Lüfter Modus“ (2) kann die der aktuelle Lüftermodus ausgelesen werden. Zum Lesen der Lüfterstufe kann die Gruppenadresse „Lüfterstufe Rückmeldung“ (3) konfiguriert werden. Zusätzlich kann durch Deklaration von einer Initialisierungsadresse (4) beim Systemstart der aktuelle Status der Funktion abgefragt werden.
  • Seite 37 Betriebsmodus: Die Funktion „Betriebsmodus“ (1) ist die Funktion zum KNX-konformen Umschalten der unterschiedlichen Betriebsmodi. Durch die Gruppenadresse „Betriebsmodusumschaltung“ (2) kann diese veranlasst werden. Je Betriebsmodus kann ein individueller Name und Wert vergeben werden (3 - 6). aktuelle Betriebsmodus kann durch Gruppenadresse „Betriebsmodus Rückmeldung“...
  • Seite 38 Basis Sollwert: Der Smart Visu Server unterstützt eine KNX-Klimareglung mittels Vorgabe eines Basis Sollwertes (1). Durch die Gruppenadresse „Basis-Sollwert“ (2) kann die Temperatur- regelung beeinflusst werden. Das Lesen des aktuellen Sollwertes kann durch die Gruppenadresse „Soll-Temperatur Anzeige“ (3) konfiguriert werden.
  • Seite 39 Sollwertverstellung: Mit der Funktion „Sollwertverstellung“ (1) kann eine KNX-Klimareglung über die Sollwertverschiebung beeinflusst werden. Durch Gruppenadresse „Sollwertverschiebung“ (2) kann die Temperaturregelung beeinflusst werden. Das Lesen der aktuellen Solltemperatur (3) sowie der aktuellen Sollwertverschiebung (4) kann durch die entsprechenden Rückmeldeadressen konfiguriert werden. Zusätzlich kann durch Deklaration zweier Initialisierungsadressen (5 - 6) beim Systemstart der aktuelle Status der Funktion abgefragt werden.
  • Seite 40 2.4.4.4 Szene Der Smart Visu Server unterstützt das Ausführen und Überschreiben von Szenenwerten. Der Funktionstyp „Szene“ kann wahlweise durch zwei differenzierte KNX-Funktionen abgebildet werden. Szene ausführen: Die Funktion „Szene ausführen“ (1) ist die Funktion zum Ausführen von KNX-Szenen. Die Funktion sendet einen Szenenwert (2) an die im Eingabefeld „Szene Gruppenadresse (1 Byte)“...
  • Seite 41 Szene ausführen & überschreiben: Die Funktion „Szene ausführen & überschreiben“ (1) ist die Funktion zum Ausführen und Überschreiben von KNX-Szenen. Die Funktion sendet einen Szenenwert (2) an die im Eingabefeld „Szene Gruppenadresse (1 Byte)“ (3) eingetragene KNX-Gruppenadresse. Durch eine lange Betätigung auf der Bedienfläche im SV-Home wird der gespeicherte Szenenwert überschrieben und durch den aktuellen Wert ersetzt.
  • Seite 42 2.4.4.5 Werte Der Funktionstyp „Werte“ kann wahlweise durch sechs differenzierte KNX-Funktionen abgebildet werden. Anzeige 1 Bit: Die Funktion „Anzeige 1 Bit“ (1) ist die KNX-Funktion zum Anzeigen von 1-Bit Statuswerten des KNX-Systems. Die Funktion liest die im Eingabefeld „Status (1 Bit)“ (2) eingetragene KNX- Gruppenadresse.
  • Seite 43 Anzeige 1 Byte (0..100%): Die Funktion „Anzeige 1 Byte (0..100%)“ (1) ist die KNX-Funktion zum Anzeigen von ganzzahligen (0…100%) Ein-Byte Werten im SV-Home. Die Funktion liest die im Eingabefeld „Wert (1 Byte)“ (2) eingetragene KNX Gruppenadresse. Da im KNX-System Werte ohne Einheit gesendet werden, kann mit dem Eingabefeld „Einheit“...
  • Seite 44 Anzeige 2 Byte (Gleitkomma): Die Funktion „2-Byte Wert anzeigen“ (1) ist die KNX-Funktion zum Anzeigen von KNX- zwei-Byte Werten (Gleitkomma) im SV-Home. Die angezeigten Werte werden auf eine Nachkommastelle abgerundet. Die Funktion liest die im Eingabefeld „Wert (2 Byte)“ (2) eingetragene KNX-Gruppen- adresse.
  • Seite 45 Anzeige 4 Byte (Gleitkomma): Die Funktion „4-Byte Wert anzeigen (Gleitkomma)“ (1) ist die KNX-Funktion zum Anzeigen von vorzeichenbehafteten Gleitkommazahlen des KNX-Systems im SV-Home. Die angezeigten Werte werden auf die erste Nachkommastelle abgerundet. Die Funktion liest die im Eingabefeld „Wert (4 Byte)“ (2) eingetragene KNX Gruppenadresse.
  • Seite 46 Anzeige 4 Byte (Ganzzahl): Die Funktion „4-Byte Wert anzeigen (Ganzzahl)“ (1) ist die KNX-Funktion zum Anzeigen von vorzeichenbehafteten ganzzahligen Größen des KNX-Systems im SV-Home. Die Funktion liest die im Eingabefeld „Werte (4 Byte)“ (2) eingetragene KNX Gruppenadresse. Da im KNX-System Werte ohne Einheit gesendet werden, kann mit dem Eingabefeld „Einheit“...
  • Seite 47 Anzeige 14 Byte (ASCII): Die Funktion „Anzeige 14 Byte (ASCII)“ (1) ist die KNX-Funktion zum Anzeigen von Texte mit maximal 14 Zeichen des KNX-Systems im SV-Home. Die Funktion kann die ASCII-Zeichen im Eingabefeld „Werte (14 Byte)“ (2) eingetragene Gruppenadresse lesen. Wird im KNX-System auf in diese Gruppenadresse ein Text geschrieben, kann dieser im SV-Home angezeigt werden.
  • Seite 48: Philips Hue Funktionen Konfigurieren

    Authentifizierung des Philips Hue Systems vorausgesetzt (Kapitel 2.3 „Hue“). Der „Benutzer“ und der „Administrator“ besitzen innerhalb der Spalte „Funktionen“ identische Zugriffsrechte auf Hue-Funktionen. Die im Reiter „Hue“ dem Smart Visu Server hinzugefügten Hue-Leuchtmittel sind automatisch in der Funktionsliste mit ihrem Namen ergänzt. Im Reiter „Bereiche & Funktionen“...
  • Seite 49: Webseite / Ip Funktionen Konfigurieren

    2.4.6 Webseite / IP Funktionen konfigurieren Damit Web-Funktionen genutzt werden können, wird eine Internetverbindung voraus- gesetzt. Zugriff als Administrator oder Benutzer Der „Benutzer“ und der „Administrator“ besitzen innerhalb der Spalte „Funktionen“ unterschiedliche Zugriffsrechte die Web-Funktionen. Zugriff Benutzer Administrator Webfunktion erstellen ...
  • Seite 50 2.4.6.1 Webseite Mit der Funktion „Webseite“ (1) kann eine Internetseite im SV-Home in wählbare Bereiche eingebunden werden. Über diese Funktion ist es z.B. möglich, Webseiten von Ihrem Lieblings-Wetterdienst einzubinden. Ebenso lassen sich so auch beliebige andere Webseiten in die Bedienoberfläche der SV-Home Ihrer Gebäudeautomatisierung ergänzen.
  • Seite 51 2.4.6.2 IP-Kamera Mit der Funktion „IP-Kamera“ (1) kann eine IP-Kamera im Smart Visu Server in wählbare Bereiche eingebunden werden. Hierüber ist es möglich innerhalb der Bedienoberfläche Ihrer SV-Home beispielsweise „Live-Bilder“ einer IP-Kamera Ihres Eingangsbereiches darzustellen. Im Eingabefeld „URL“ (2) kann die darzustellende Web- / IP-Adresse eingegeben werden.
  • Seite 52: Statuslogik Funktionen Konfigurieren

    2.4.7 Statuslogik Funktionen konfigurieren Der Smart Visu Server unterstützt „Statuslogik“ (1), mit denen bis zu 10 Funktionszustände logisch miteinander verknüpft werden können. Mit einer Statuslogik können Sie beispielsweise den Zustand Ihrer Fensterkontakte miteinander verknüpfen, so dass Sie in der SV-Home auf einen Blick sehen können, ob alle Fenster geschlossen sind.
  • Seite 53: Funktion Bearbeiten Oder Löschen

    2.4.8 Funktion bearbeiten oder löschen Zugriff als Administrator oder Benutzer Der „Benutzer“ und der „Administrator“ besitzen innerhalb der Spalte „Funktionen“ unterschiedliche Zugriffsrechte auf KNX-Funktionen. Um alle Funktionen editieren und löschen zu können müssen Sie Administratorrechte besitzen. Zugriff als Administrator Um eine bestehenden Funktion (1) zu editieren oder zu löschen, muss dieses ausgewählt sein.
  • Seite 54: Aktion

    Aktionen können in der SV-Control in der Registerkarte „Aktionen“ (1) erstellt, bearbeitet und gelöscht werden. Die Registerkarte ist mit beiden Profilen (Administrator / Benutzer) vollständig bedienbar. Der Smart Visu Server unterstützt die Erstellung von bis zu 250 Aktionen. 2.5.1 Aktion erstellen Um eine neue Aktion zu erstellen, geben Sie im Eingabefeld (2) den Namen Ihrer neuen Aktion ein und betätigen Sie anschließend die Schaltfläche „...
  • Seite 55 Abbildung 41: Registerkarte „Aktionen“ Jede Funktion, die der ausgewählten Aktion zugeordnet ist, wird unterhalb des Auswahlmenüs (10) in einer Funktionsliste (10a) aufgeführt. Die Parameter (10b) jeder Funktion können separat eingestellt werden. Je nach Funktionstyp stehen unterschiedliche Bedienelemente zur Verfügung. Diese entsprechen den elementaren Bedienelementen der jeweiligen Funktion in der SV-Home.
  • Seite 56 2.5.1.1 Zeitschaltpunkt Der Aktionstyp „Zeitschaltpunkt“ (9) löst abhängig vom Wochentag und der eingestellten Tageszeit automatisch aus. Zusätzlich können Sie diesen Aktionstyp individuell über die SV-Home auslösen. Die Auslösezeit können Sie mit den Pfeilen „ “(9a) einstellen. Nebenstehend können Sie die Wochentage (9b) festlegen, an denen die Aktion ausgeführt wird. Aktive Tage sind blau hinterlegt.
  • Seite 57: Aktion Bearbeiten Oder Löschen

    2.5.2 Aktion bearbeiten oder löschen Um eine Aktion zu bearbeiten oder zu löschen, müssen Sie diese in der Liste „Aktionen“ (1) zunächst auswählen. Die in der Liste (1) ausgewählte Aktion wird in der Spalte „Aktionen Bearbeiten“ (2) editierbar angezeigt. Eine ausgewählte Aktion kann mit dem Symbol „ “...
  • Seite 58: Konfigurationsverwaltung

    Erreicht werden kann die Konfigurationsverwaltung in der SV-Control über den Reiter „ “ (1). Die Registerkarte ist mit beiden Profilen (Administrator / Benutzer) vollständig bedienbar. Abbildung 47: Registerkarte der Smart Visu Server Konfiguration SV- SERVER / SV-SERVER-INT 57 / 150...
  • Seite 59: Netzwerkeinstellungen

    Weitere Informationen finden Sie hierzu im Kapitel 1.5 „Geräteaufbau, Funktion“ 2.6.1.2 Setzen einer statischen IP-Adresse Um nach der Inbetriebnahme dem Smart Visu Server eine statische Adresse manuell zuzuweisen, kann mit dem Punkt „statisch“ (2b) aktiviert werden. Die Eingabefelder (2c bis 2f) sind danach editierbar.
  • Seite 60: Systemzeit Und Datum Einstellen

    Abbildung 49: Parameter der Zeiteinstellung 2.6.3 Serverupdate Um ein Systemupdate durchführen zu können benötigt der Smart Visu Server Zugang zum Internet. Je nach Internetgeschwindigkeit kann dieser Vorgang mehrere Minuten dauern. Es wird für die Dauer des Updates empfohlen, die Strom- und Netzwerkverbindung nicht zu unterbrechen.
  • Seite 61 Abbildung 51: Darstellung eines laufenden Updates Nach dem Einspielen des Updates wird das System neu gestartet. Während des Systemneustarts wird ein Rückwärtszähler (4c) eingeblendet. Kurz nachdem dieser 0 erreicht kann SV-Control wieder wie gewohnt bedient werden. Der Update Vorgang ist damit abgeschlossen.
  • Seite 62: Sv-Home

    Die SV-Home wird automatisch aus der im SV-Control erstellten Konfiguration generiert und kann in drei Abschnitte unterteilt werden. Der oberste Abschnitt ist immer sichtbar und besteht aus dem Jung-Logo sowie dem Schriftzug „SV-Home“ (1). Durch Betätigung des Schriftzuges „SV-Home“ (1) gelangen Sie zurück zur Startseite und können somit in die SV-Control wechseln.
  • Seite 63: Update Des Smart Visu Servers

    Als Teil dieser Bemühungen stellen wir Updates für die Systemsoftware zur Verfügung. 4.1 Softwareversion auslesen Die aktuell auf Ihrem Smart Visu Server installierte Softwareversion können sie über SV- Control auslesen. Diese wird in allen Registern der SV-Control im unteren Bereich angezeigt (1).
  • Seite 64: Anhang

    5 Anhang 5.1 Zubehör Empfohlen wird die Verwendung eines der folgenden KNX-IP-Datenschnittstellen: Fa. Jung: KNX IP-Schnittstelle Art.-Nr.: IPS 200 REG Fa. Jung: KNX IP-Router Art.-Nr.: IPR 200 REG SV- SERVER / SV-SERVER-INT 63 / 150...
