Activate & Learn Scene (KNX):
The "Activate and Learn Scene (KNX)" function (1) is a Smart Visu Server function for
executing KNX scenes.
The function transmits a scene value (2) to the KNX group address entered in the input
field "Scene group address (1 Byte)" (3). With each KNX scene group address, up to 64
scene values (or scene numbers) (2) can be recalled. The scene value (2) the Smart Visu
Server should transmit when a scene is triggered can be set in the input field (2).
4
1
2
3
Figure 86: Parameters of the "Activate and learn" function
The function possesses the following individualisation options within the icon library (4).
KNX function
Selection of the icon library in SV-Control
Operating and display element in SV-Home
Activate & learn
scene
Table 44: Display of the "Activate & learn scene" function
SV- SERVER / SV-SERVER-INT
101 / 150
