6.7.1 SV-Home – User interface
The SV-Home is the integrated web interface of the Smart Visu Server for the
visualisation, status display and operation of the KNX system and the Philips Hue system.
The SV-Home is generated automatically from the configuration set up in SV-Control.
A current HTML5-compatible browser (input device) is required for access to SV-Home.
When the server is opened, the SV-Home visualisation can be started by selecting the left
button (1).
The top pane (1) displays the areas created in SV-Control with the selected icon and
name. Selecting an area displays the assigned functions and actions (2) beneath.
Depending on the created function type, these functions visualise their status (e.g. the
current room temperature) or offer a chance to influence it (e.g. move a Venetian blind or
dim a Philips Hue lamp).
SV- SERVER / SV-SERVER-INT
1
Figure 58: Opening SV-Home
Figure 59: Structure of the SV-Home visualisation
Areas (1)
Functions / actions (2)
