3.5.2 Connection PTC – Kenwood
Most Kenwood transceivers that use 13 pin DIN plug (ACC2) can be connected this way:
Signal
GND
PTT
AF-OUT
AF-IN
This cable is available completely assembled.
Refer to chapter
The TS-50 can only be connected via the microphone jack:
Signal
GND
PTT
AF-OUT
AF-IN
The TS-480 has a 6 pin Mini-DIN connector:
Signal
GND
PTT
AF-OUT
AF-IN
This cable is available completely assembled.
Refer to chapter
3.5.3 Connection PTC – YAESU
Some YAESU transceivers use a 5 pin DIN plug (Packet) and can be connected this way:
Signal
GND
PTT
AF-OUT
AF-IN
Smaller YAESU's use a 6 pin Mini-DIN-connector, whereby with multiband transceivers two
different connection schemes must be distinguished:
PTC Color
PIN 2 white
PIN 3 yellow
PIN 1 violet
PIN 4 green
5 on page 49.
Table 6: KENWOOD
PTC Color
PIN 2 white
PIN 3 yellow
PIN 1 violet
PIN 4 green
Table 7: KENWOOD TS-50
PTC Color
PIN 2 white
PIN 3 yellow
PIN 1 violet
PIN 4 green
5 on page 49.
Table 8: KENWOOD 6 pin Mini-DIN
PTC Color
PIN 2 white
PIN 3 yellow
PIN 1 violet
PIN 4 green
Table 9: YAESU 5 pin
Kenwood
PIN 4, 8, 12
PIN 9
PIN 11
PIN 3
Kenwood
PIN 7, 8
PIN 2
PIN 1
PIN 6
YAESU
PIN 2
PIN 3
PIN 1
PIN 5
YEASU
PIN 2
PIN 3
PIN 1
PIN 4
