12.10 Spare and wear parts list, hose unit, complete (001366512)

6
7
6
Fig. 16: Explosion drawing, hose unit, complete
Item No.
1 Exhaust air hose
2 Screw-on nozzle
3 Pressure hose
4 Threaded fitting
5 Hose clamp
6 Screw clip
7 Ring
8 Housing
9 Disc
10 Ring
Tab. 9: Spare and wear parts list, hose unit, complete
Schmid & Wezel
5
2
1
Designation
Seite / Page
51 / 53
3
8
Article No.
001331183
001366108
001366316
001367102
001369402
001371924
003011219
003011291
003011292
003011293
4
2
5
10
9
Quantity
1
2
1
1
2
2
1
1
1
1
Ausführung / Version
02 / 2011
