10.

Technical Data

Name
Power output
Working pressure
Air consumption
Speed (saw blade)
Saw blade
Cutting depth
Sound pressure level (EN ISO 11688-1)
Hand-arm vibration (EN 28662)
Weight
Connections on the maintenance unit
Hose length
Tab. 2: Technical Data
11.

Dimensional Drawing

11.1 Rib saw EFA SK16-8D

165
Fig. 7: Dimensional drawing, EFA SK16-8D
Schmid & Wezel
Unit
EFA SK16-8D/ SK16-8DR
W
bar
l/min
-1
min
mm
mm 15 - 45 (adjustable)
dB(A)
2
m/s
kg
Inches
m
220
371
Seite / Page
40 / 53
Features
790
7
900
2000
160
> 85 possible
< 2.5
2,7
R 3/8"
5
Ausführung / Version
EFA SK18-8D
790
7
900
2000
180
60
> 85 possible
< 2.5
3,1
R 3/8"
5
19,5
68
02 / 2011
