Re:sound I - ICS 50/ 80 – IWS 51/ 80
Adjusting speaker colour
Painting the frame
Using the supplied painting
template, the speaker can be
coloured to match its environ-
ment. To do this, you should first
remove the speaker grill and fix
the painting template in its place,
using decorator's masking tape.
Make sure that no spray mist can
penetrate the speaker housing
from the side during painting.
Painting the speaker grille
You should remove the internal
fleece first, if the grill also is to be
painted. The fleece has an
adhesive surface, which allows
you to put the fleece back in
position once the paint has dried.
If the fleece does not adhere any
more, you can use a standard
spray adhesive.
Disassembling
Hold the speaker in position and
unscrew the four fixing screws
until the head of the screw
protrudes by about 1 mm. The
four rotary tensioners are now
back in the install position and
the speaker can be removed.
11
Technical hints
Cable lengths
In order to keep the line and
treble loss as low as possible, we
recommend that you use the
following cable profiles and in
any case, you should use 2-core
wire.
Up to 15 m:
Ø 0.75 mm
Up to 30 m:
Ø 1.50 mm
Over 30 m:
Ø 2.50 mm
Up to 50 ft:
AWG 17
Up to 100 ft:
AWG 14
Over 100 ft:
AWG 12
We advise that you avoid using
cable lengths above 50 metres,
in order to avoid loss of hi-fi
reproduction.
Load capacity
It is possible to operate these
speakers with amplifiers that
have a higher output
performance. In this case
however, you must ensure that
the volume is only turned up to a
level where your ear (usually a
reliable measure) starts to notice
an overload.
Your Revox speakers will not be
damaged by a short-term
overload.
2
2
2
