Re:sound I - ICS 50/ 80 – IWS 51/ 80
INSTALLATION - Preparation
Installation in suspended ceilings or hollow walls
You need to use the supplied
fitting template when doing a
standard installation of the fitted
speakers in a suspended ceiling
or wall.
ICS 50 – Installation opening
IWS 51 – Installation opening
148 mm
5.83 inch
Max. wall thickness: 32 mm
5
Make sure that once the opening
has been cut out, no dirt remains
in the installation opening and
that any movable parts are fixed
in place.
ICS 80 – Installation opening
IWS 80 – Installation opening
222 mm
8.75 inch
Max. wall thickness: 32 mm
