Exploded View - Poolex NANO Turbo Installations- Und Gebrauchsanleitung

2.5

Exploded view

15
16
13
14
17
18
1. Front panel
2. Fan and motor
3. Fan support
4. Electrical control box
5. Base plate
6. Compressor
7. Low pressure switch
8. Angular support
9. 4-way valve
2. description
比例 1.000
10. Evaporator
11. Top panel
12. Throttling parts
13. Flow switch
14. Heat exchanger
15. Pressure gauge
16. Left side panel
17. Control panel
18. Fan protective grill
11
10
9
7
8
4
3
2
6
5
1
EN | 13
