Cordless Hot Glue Gun
•
Charger
•
Original operating instructions
•
Safety instructions
s.

3. Proper use

You can use the cordless hot glue gun to glue the
s
following materials: Wood, plastics, textiles, card-
board, ceramics, leather, etc.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse. The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.

4. Technical data

he
Power supply: ........................................ 3.6 V DC
Heating time: ........................ approx. 30 seconds
g
Melting temperature: ................................ 160 °C
ll
Glue stick diameter: ................................... 7 mm
Battery capacity: ....................................... 1.5 Ah
ing
Battery type: ...................................... Lithium-ion
p- Weight: .....................................................0.25 kg
Charger for TC-CG 3.6/1 Li
Battery charge voltage: ......................... 5,5 V DC
Battery charge current: ............................ 600 mA
Charging unit
r
supply voltage: .................. 100-240V~ 50-60 Hz
Charging time: .....................................3 - 5 hours
l
Caution!
Residual risks
Even if you use this electric power tool in
e
accordance with instructions, certain resi-
ic
dual risks cannot be rules out. The following
r of
hazards may arise in connection with the
equipment's construction and layout:
1. Lung damage if no suitable protective dust
mask is used.
Anl_TC_CG_3_6_1_Li_SPK9.indb 15 Anl_TC_CG_3_6_1_Li_SPK9.indb 15
GB

5. Before starting the equipment

Hazard!
Charge the equipment only with the charger sup-
plied.
Only place the equipment on non-fl ammable
surfaces.
5.1 Charging the battery (Fig. 2)
The battery is protected from exhaustive dischar-
ge. An integrated protective circuit automatically
switches off the equipment when the battery is
fl at.
Note! Do not actuate the On/Off switch any more
if the protective circuit has tripped. This may da-
mage the battery.
Check that your mains voltage is the same as the
one marked on the rating plate. Connect the USB
plug type A (5a) of the charging cable (5) to the
charger (6). Connect the battery charger to the
socket and connect the USB connector type Mic-
ro B (5b) of the charging cable (5) to the charging
connection (a) of the cordless hot glue gun.
The LED (2b) will light up red to indicate that the
battery pack is being charged. When charging is
fi nished, the LED (2a) will light up green.
If the LED (2b) fl ashes red, this indicates that the
temperature is too high or too low. Keep the tool
at room temperature for a day and try again.
If no LEDs come on or fl ash during charging, this
means that the battery pack is defective. A defec-
tive battery is not allowed to be used any more.
Important! The handle may become a little warm
during the charging process. This is normal.
If the battery fails to charge, please check
•
whether there is voltage at the socket outlet
•
whether there is good contact at the charging
contacts of the charging unit
If the battery still fails to charge, send
•
the charging unit
•
and the cordless hot glue gun
to our customer service center.
5.2 Inserting the glue stick (Fig. 3)
Push the glue stick (b) into the opening (c) as far
as the stop.
