8 Specifications

Wireless camera
Approval number: . . . . . . . .
Transmitting power: . . . . . . . 10 mW
Image sensor: . . . . . . . . . . . 8.5 mm (
Number of pixels: . . . . . . . . . hor. 512, vert. 582
Resolution: . . . . . . . . . . . . . . 380 lines
Lens: . . . . . . . . . . . . . . . . . . 1 : 2.0/3.6 mm (92°)
Minimum illumination: . . . . . 3 lux
S/N ratio: . . . . . . . . . . . . . . . > 40 dB
Automatic electronic shutter:
Power supply: . . . . . . . . . . . 9 V /300 mA via sup-
Protective class of housing: . IP 44
Dimensions (W x H x D): . . . 100 x 145 x 275 mm
Weight (with bracket): . . . . . 820 g
Receiver
Outputs
video: . . . . . . . . . . . . . . . . 1 Vpp/75 Ω
audio: . . . . . . . . . . . . . . . . 500 mV/1 kΩ
Power supply: . . . . . . . . . . . 9 V /300 mA via sup-
Dimensions (W x H x D): . . . 170 x 45 x 135 mm
Weight: . . . . . . . . . . . . . . . . . 265 g
Common specifications
Transmission frequencies: . . 2.414 GHz
Max. range: . . . . . . . . . . . . . approx. 100 m in the
Signal size: . . . . . . . . . . . . . CCIR
Colour system: . . . . . . . . . . . PAL
Ambient temperature: . . . . . 0 – 40 °C
According to the manufacturer.
Subject to change.
0681
!
1
/ ") CMOS
3
1 1
/ – / s
50 15 000
plied power supply unit
at 230 V~/50 Hz/5 VA
plied power supply unit
at 230 V~/50 Hz/5 VA
2.432 GHz
2.450 GHz
2.468 GHz
open space (reduced
range in buildings)
625 lines
50 single frames/s
GB
