4.4

Unlock device

The unlock code can be used to start the vehicle by delivering a breath
sample in the event of a device lockout (for example because of expiry
of the service period due to legal requirements), after entering a code
number.
1. To obtain the code number, call the service phone number and
have the following information ready:
Serial number of the handset.

Date and time (hours and minutes) at which the code number

has to be entered.
NOTICE
i i
The code number is accepted for a period of up to
15 minutes after the specified time.
2. Select option Unlock device and confirm.
The display shows _ _ _ _.
3. Select and confirm the desired first figure.
4. Afterwards set the next figure.
5. Repeat the procedure for all figures.
6. Select Confirm or Cancel:
Pressing cancel will exit the menu.

On confirmation, the instrument will request a breath alcohol test.

4.5

Access code

The access code can be used to start the vehicle without delivering
a breath sample, for example in a garage, for a limited time period after
entering a code number.
1. To obtain the code number, call the service phone number and
have the following information ready:
Serial number of the handset.

Date and time (hours and minutes) at which the code number

has to be entered.
Dräger Interlock 5000 / 7000
NOTICE
i i
The hour entered indicates how long the access code is
valid for. Example: When it shows 14:00 the access code can
be used from 14.00 to 14.59.
The access is (depending on setting) possible for a maximum
of 48 hours after entering the code number.
2. Select option Enter code and confirm.
The display shows _ _ _ _.
3. Select and confirm the desired first figure.
4. Afterwards set the next figure.
5. Repeat the procedure for all figures.
6. Select Confirm or Cancel:
Pressing cancel will exit the menu.

NOTICE
i i
The validity of the access code can be terminated by requesting
a new breath alcohol test (see Chapter 4.1 on page 30).
4.6

Configuration

4.6.1

Display

This function can be used to set the brightness of the display. There are
3 preset brightness levels to choose from.
4.6.2

Language

This function can be used to change the instrument language.
4.6.3

Communication

This function can be used to switch communication between Bluetooth
and infra-red channels.
Menu
31
