Icom IC-7100 Bedienungsanleitung Seite 9

Selectivity
Spurious and image
rejection ratio
Audio output power
SSB (BW=2.4kHz, sharp):
More than 2.4kHz / −6dB
Less than 3.4kHz / −40dB
CW (BW=500Hz, sharp):
More than 500Hz / −6dB
Less than 700Hz / −40dB
RTTY (BW=500Hz):
More than 500Hz / −6dB
Less than 800Hz / −40dB
AM (BW=6kHz):
More than 6.0kHz / −6dB
Less than 10kHz / −40dB
FM (BW=15kHz):
More than 12kHz / −6dB
Less than 22kHz / −40dB
DV (12.5kHz spacing):
More than −50dB
More than 70dB (HF/50/70MHz)
More than 65dB (144/430MHz)
(except 1/2 IF through on 50/70MHz,
IF through on 144MHz)
More than 2.0W
(10% distortion, 8Ω load, 13.8V DC)
9
