6. Internal rechargeable batteries

The ClearNote+ can be powered either by mains power or by the internal
rechargeable batteries. The batteries enable 5 hours of continuous use.
Recharging takes approximately 4 hours. When using the unit while
charging, charging will take longer.
To charge the batteries, connect the ClearNote+ to the mains power by
connecting the power adapter. The Blue LED light on the camera arm
indicates the batteries are charging. The LED turns off when the batteries
are fully loaded. The LED is indicated with the symbol:
+

7. Operation of the ClearNote

The ClearNote+ can be operated both from the camera stand and from
the computer keyboard - see also chapter 8 and 9.
Switching on & off
The on / off switch is placed on the top end of the camera arm.
Switch the ClearNote+ on. The green LED light on the camera
arm indicates the ClearNote+ is switched on.
It takes approximately 5 seconds for the camera to initialize.
During this time, no buttons should be pressed.
Resetting the ClearNote+ to factory default settings
In case of erratic behaviour of the unit, you can manually reset
the ClearNote+ to factory default settings as follows: Switch the
ClearNote+ off. Then hold the + and – button while switching on the
ClearNote+ camera. Hold the buttons until the red Led light starts
blinking.

Setting the magnification

The two oval shaped buttons on the camera stand are
used for selecting your preferred magnification setting.
By pressing the " + " or the " - " button you can increase or
decrease the magnification.
External light
This switch is placed at the top end of the camera stand and
activates and de-activates the external light. Switching on the
external light is accompanied with a short beep. The external
light can only be activated when the ClearNote+ is switched on.
