4 Damping of swing doors
In the case of concealed hinges
Damping can be activated or deactivated at each hinge as
required. Just push using the finger.
Damping off
Press slider inwards [Figure 1].
Damper folds in the next time the door is closed [Figure 2].
Damping on
Press slider forwards [Figure 3].
Damper folds forwards [Figure 4].
Caution! In the case of small doors, damping at just
one hinge may be sufficient.
Caution!
Damping is active when the unit is delivered!
Caution! When the doors are opened and closed, it is
possible for items or fingers to become trapped be-
tween the door and the side of the unit. If the units are
used in teaching establishments then their use must be
supervised and the doors must be closed after use.
12
2
4
5
5 Gratnells trays:
Removing: Pull the boxes forwards as far as the stop and
then lift them until they pass above the pull-out lock. You
can then remove the box [Figure 5].
Inserting: Insert the boxes from above until they are cor-
rectly positioned in the guide rail. Then push them in hori-
zontally as far as the stop.
Caution! If cabinets are equipped with materials boxes
then these boxes must be fully inserted before the
units are moved.
