6.3

Troubleshooting

Important!
The following table provides information on
faults and their probable cause. If you cannot
rectify a fault using the table, please contact
your authorised dealer directly.
Problem Possible
causes
No motor noise/lift Jack socket of the
does not move hand control is not
locked correctly
The battery is flat
The contacts are
dirty
The cable is dam-
aged
The lift can be Low-voltage pro-
raised but not low- tection is activated
ered
The lift stops while The load is exces-
being raised sive
The battery can- The electronics
not be recharged are faulty
The battery is
faulty
The charger is
faulty
The bathlift slips The suction cups
are old or dam-
aged
7

Care and maintenance

7.1

Seat and backrest

CAUTION!
There is a risk of injury when the lifting scis-
sors move.
Be especially careful when cleaning the
seat.
There is a risk of damage.
Never clean the backrest with a high pres-
sure cleaner.
16
Remedy
Lock the jack
socket (see sec-
tion 5.2)
Recharge the bat-
tery (see
section 5.1)
Clean the contacts
Replace the hand
control
Recharge the bat-
tery
Observe the maxi-
mum load
Have your author-
ised dealer check
the hand control
Replace the hand
control
Have the charger
checked
Replace the suc-
tion cups
Important!
● Regularly clean the seat and backrest and
keep them clean.
●
Do not use abrasive cleaning agents.
1. Wash the product with commercial detergents and
disinfectants using a cloth or brush.
2. Rinse the product with warm water.
3. Dry the product with a cloth.
4. Lightly grease the guide for the sliding shoe (8,
fig. 1) using Vaseline.
5. Unbutton the covers (optional) from the seat and
backrest.
CAUTION!
There is a risk of damage.
Do not tumble-dry the covers.
6. Wash the covers (optional) in the washing ma-
chine at maximum 60 °C using a mild detergent.
7.2

Charger and hand control

CAUTION!
There is a risk of injury from electric shock.
● Before cleaning the charger, always pull
the plug out of the power socket.
●
Never plug objects made of conducting
material (e.g. knitting needles, metal
pins) into the jack socket of the hand
control.
● Only use a dry cloth to clean the
charger.
1. Wipe down the charger with a dry cloth.
2. Wipe down the hand control with a damp cloth
and dry it with a dry cloth.
