Unpacking the machine

Check all parts for any transport damage. Inform the
transport agent immediately of any faults. Make sure the
delivery is complete. Inform the dealer immediately in
case something is missing.
Additional parts that are to be attached to the machine,
must be located and identified before assembly.
Attention: Fill in oil before putting into operation.
Attention! Check the oil level prior to commissioning!
As standard, your plate vibrator is equipped with an oil
monitor that protects the engine from damage if the oil
level is too low.
Attention:
If the oil level is too low, the engine switches itself off;
in this case, proceed as described in the maintenance
section in figure 5 and add oil.
1 Vibratory plate with motor
2 Handle
3 Wheel base
4 Rubber mat with fastening bar
Small parts
Operating instructions
Equipment Fig. 1
1 Vibratory plate
2 Eccentric
3 Drive
4 Motor
5 Gasoline tank
6 Air filter
7 Exhaust pipe
8 Lower handle
9 Upper handle
10 Gas lever
