SPX II
Key:
Material selection
Key:
Photocell
Scan position (AP)
Key:
Label error length
Synchronisation
Key:
Flip label
Key:
Rotate label
Key:
Rotate label in degrees
Key:
Alignment

Device Settings

Keys: , , ,
Field handling
Key:
Codepage
120
Selection of the used label and transfer ribbon material.
Selection of the used photocell.
Possible selection: transmission photocell normal, transmission photocell inverse, ultrasonic
photocell (option).
Entry of percental label length by that the label end is searched.
In case an error occurs, indication after how many mm a message appears in the display.
Value range: 1 ... 999 mm
On: If a label is missed on the liner an error message is displayed.
Off: Missing labels are ignored, i.e. it is printed into the gap.
The axis of reflection is in the middle of the label. If the label width was not transferred to the
printer, automatically the default label width i.e. the width of the printhead is used. It is
recommended to use labels with the same width as the printhead. Otherwise this can cause
problems in positioning.
According to standard the label is printed ahead with a rotation of 0°.
If the function is activated, the label is rotated by 180° and printed in reading direction.
Corresponding to the parameter Rotate label, the label can be turned in 90° steps.
NOTICE!
Only printer internal objects (text, lines and barcodes) can be turned. The rotation
of graphics is not possible.
The adjustment of label is effected only after 'flip/rotate label', i.e. the adjustment is independent
of the functions flip and rotate label.
Left: The label is aligned at the left-most position of printhead.
Centre: The label is aligned at central point of printhead.
Right: The label is aligned at right-most position of printhead.
Off: The complete print memory is deleted.
Keep graphic: A graphic res. a TrueType font is transferred to the print module once and
stored in the print module internal memory. For the following print order only the modified data is
transferred to the print module. The advantage is the saving of transmitting time for the graphic
data.
The graphic data created by the print module itself (internal fonts, bar codes, ...) is generated
only if they were changed. The generating time is saved.
Delete graphic: The graphics res. TrueType fonts stored in the internal memory is deleted but
the other fields are kept.
Indication of the font used in the print module. The following possibilities are available:
Codepage 437, Codepage 850, Codepage 852, Codepage 857, Codepage 1250, Codepage
1251, Codepage 1252, Codepage 1253, Codepage 1254, Codepage 1257, WGL4.
Please find the tables referring to the above mentionned character sets on our website.
