Autoadapt Turny Evo Installations Anleitung Seite 29

A Energy bracket
C 7/16 UNF x 22
D 7/16 UNF
E 12.5x26x2
Wire in connections
1
E.g.
B / lower anchor point
with belt pretensioner.
x 1 B
x 4
x 4
x 2 (if necessary)
x 12
2
1
Loosen the cable, located
on the lift motor and
attach it to the plate.
Energy bracket x 1
3
4
2
Wirning from
Turny Evo.
3
Getting seated Turny Evo
E.g.
B / female connector with
belt pretensioner and switch.
4
E.g.
OEM wiring under seat.
