involight TRINITY200LED Bedienungsanleitung Seite 28

Curve
Reset
Pan
Tilt
Dimmer
Strobe
Cyan
Magenta
Yellow
Color1
Color2
Color3
Fixed -Gobo
Manual
Rot-Gobo
Rot-Gobo Rot
Iris
Prism1
Prism1 Rot
Prism2
Prism2 Rot
Frost
Focus
Zoom
Run Mode Stop
a) Press the ► button (Enter) until "Swap Pan-Tilt" is displayed.
b) Press the ▲ (Up) or ▼ (Down) buttons until "On" or "Off" is
displayed.
c) To confirm and exit the menu press the key ► (Enter), or
"OK"
d) Press the ◄ (Return) key to exit the selection without saving
Exp -Curve
This allows you to select the desired dimming curve.
a) Press the ► button (Enter) until "Dimmer Curve" is displayed.
Linear
b) To select the desired dimming curve, press the ▲ (Up) or ▼
(Down) buttons.
c) To confirm and exit the menu press the key ► (Enter) or "OK"
d) Press the ◄ (Return) key to exit the selection without saving.
Log-Curve
S-Curve
Head Reset
This function allows you to reset the device.
a) Press the ► button (Enter) until "Reset" is displayed.
b) To select the desired reset functions, press the ▲ (Up) or ▼
(Down) buttons.
Pan/Tilt Reset
c) To confirm and exit the menu press the key ► (Enter) or "OK"
d) Press the ◄ (Return) key to exit the selection without saving.
All reset
0-255
0-255
0-255
Operating mode "Manual control"
0-255
The "manual control" mode can only be activated if the device is
0-255
working alone or master is in a master-slave combination. This
0-255
setting is only relevant if the device is not controlled by DMX.
0-255
0-255
a) Press the ► button (Enter) until "Manual" is displayed.
0-255
b) To select the desired parameter, press the ▲ (Up) or ▼
0-255
(Down) buttons.
c) Press ► (Enter) or "OK" to edit the values.
0-255
d) Press the ▲ (Up) or ▼ (Down) buttons to select the value
0-255
between "0" and "255".
0-255
e) To confirm and exit the menu, press the ► (Enter) or "OK"
0-255
button.
f) Press the ◄ (Return) key to exit the selection without saving.
0-255
0-255
0-255
0-255
0-255
0-255
0-255
27
