dirna Bergstrom bycool COMPACT 3.0 RENAULT Montageanweisungen Seite 20

COMPACT 3.0
EN
Following this order:
7
plane rubber wash, plane ruber wash wide
wing diameter 8, nut M8, plane washer
diameter 8 wide wing.
7
Place (2) fastening supports, with (1) washer
8
and (1) M8 self-blocking nut, without
tightening.
8
Screw 10 mm deep (4) M6 studs, where
9
indicated distance (D) in figure point 18.
9
7
8
20
9
9
®
8
